China temporary outdoor warehouse big tent 15mx50m
No pole inside, 100% huge space to use
We are one of the leading manufacturers in Suzhou China having specialized in clear span tent for 9 years. Our Clear span tents are the perfect solution for any event, wedding, party, warehouse ect.
The sleek structure is made of an aluminum frame covered with a PVC fabric. Since frame tents do not
rely on tension, a minimal number of stakes is required and there is no need for center poles to support
the tent. Thus, our tent can be in maximum utilization.
Specifications
China temporary outdoor warehouse big tent 15mx50m
1.Aluminum 6061/T6 frame
2.Double pvc coated
3.TUV certificate
1. Sizes available
The clear-span width of the custom tent is available with 3m to 60m.
The length of the custom tent could be from 10m to 80m, and +5m more.
| Wide | Bay Distance | Side Height | Ridge Height | Roof Pitch | Wind Load | Frame Profile Size |
| 12m | 5m | 3m | 4.9m | 18° | 80-100km/h | 166x88x3mm |
| 15m | 5m | 3m | 5.7m | 18° | 80-100km/h | 166x88x3mm |
| 18m | 5m | 3m | 5.9m | 18° | 80-100km/h | 166x88x3mm |
| Wide | Bay Distance | Side Height | Ridge Height | Roof Pitch | Wind Load | Frame Profile Size |
| 20m | 5m | 4m | 7.5m | 18° | 80-100km/h | 200x115x4mm |
| 25m | 5m | 4m | 8.0m | 18° | 80-100km/h | 250x115x4mm |
| 30m | 5m | 4m | 8.8m | 18° | 80-100km/h | 300x125x4mm |
| Wide | Bay Distance | Side Height | Ridge Height | Roof Pitch | Wind Load | Frame Profile Size |
| 40m | 5m | 4-5m | 9.8m | 18° | 80-100km/h | 300x125x4mm |
| 50m | 5m | 4-5m | 11.4m | 18° | 80-100km/h | 300x125x5mm |
| 60m | 5m | 4-5m | 15.3m | 18° | 80-100km/h | 400x140x6mm |
2. Material of the warhouse tent
1). Frame struss: hard pressed extruded aluminium 6061 /T6 (15HW) which can last 15 to 20 years.
2). Fabric cover: high quality double PVC-coated polyester textile, 100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV resistant, tear resistant, self-cleaning ability, etc.
3). Connecter: strong hot-dip galvanized steel, zinc thickness over 80um.
3. Features & Specification of the warehouse tent
1). Allowed temperature condition: -30 degree Celsius~+70 degree Celsius
2). Wind load: max. 100km/h (can be reinforced)
3). Easy to be assembled and dismantled, removeable
4). No pole inside, 100% room is available
5). Sizes can be customized(like side/leg height)
4. Optional accessories for the warehouse tent
1). covers: colourful cover, transparent cover, inflatable roof cover
2). sidewalls: glass wall,PVC hard wall, sandwich pannel wall, fiber glass wall
3). windows: dome or square clear PVC windows, mesh window, glass window
4). doors: double-swings glass door, single-swing glass door, glass fire door, hard PVC door, rolling door
5). wooden flooring system
6). rain gutters (inner roof beam rain gutter or rain gutter between two tents)
7). drapers, curtain, lighting, AC, carpet, etc.
5. Optional Fixing methods for the warehouse tent
1). Ground anchor(steel peg): For soft ground surface like, earth, sand, lawn, etc.
2). Inflatable screw: For hard surface like, cement, stone, or prefab concrete cubic, etc.
3). Weight plate: For protective ground surface like marble, ceramic & tiles, asphalt, brick, etc.
Fix way:
6. Product Show:
More product
Please click: Suzhou WT Tent Co.,Ltd
Details:
1. Design are available.
2. Printing are available.
3. Free samples are available.
4. 24 hours online srevice.
5. Visiting easily.(1hour from Shanghai Hongqiao Airport to our company)
