frequency convex probe portable veterinary ultrasound machine
Product parameters:
Using the latest cortex-m4 embedded control system + miniaturized exclusive ultrasound technology hardware system; MSU3 has triple function of A scan, B scan and ear tag scan, the perfect solution to the various needs of users;
3.5" high resolution color LCD, small size, light weight and portable,suitable for outdoor use;
Menu interface operation, Language: Chinese/English switchable;
Gray:256
Display mode:B, 2B, A, total 3 kinds.
B mode and A mode gain range: 27 ~ 90dB
Near field gain: -31 ~ 0dB;
Far Field Gain: 0 ~ 31dB;
Dynamic range:27~90dB
3 kinds of depth range, 126,163,200, the maximum display depth of 200mm;
Compression curve adjustment: 4 kinds, from 0 to 3;
| Main unit size | 90×98×25mm(length x width x height) |
| Net Weight | 620g; |
| Battery Configuration | Large capacity (2600mAh) lithium battery can support more than 300 minutes work; |
| Dual power supply. Power | 100-240V ~ ± 10% 1.2-0.6A Frequency: 50-60Hz ± 1Hz; |
| Support multiple languages | Chinese, English, French, German, Spanish, Portuguese; |
| Pseudo-color function | 0 ~ 7,8 species (including black and white); |
| Image Storage | image or measurement data stored in the U disk; |
| Pseudo-color function | 0 ~ 7,8 species (including black and white); |
| Frame correlation | 0 ~ 5,6 kinds; |
| Frequency | 2.5M, 3.5M; |
Domestic and foreign standard configuration
Main unit: 1 pc
3.5MHz waterproof mechanical sector probe : 1 pc.
Power adapter: 1 pc
Internal battery : 1pc
Power line : 1 pc
Shutter line : 1 pc
Straps : 1 pc
Instrument backpack : 1 pc
OTG U disk : 1 pc
1. OEM/ODM service : Darppon offers OEM/ODM service for distributor to establish long term business relationship.
2. Warranty :Darppon offers 18 months free after-sale service for customers, and be responsible for life-time repair.
3. Technical support:Darppon offers professional engineers for customers on the technical support, and response within 12 hours
