Specifications
YG8 Tungsten Carbide Ball1 YG8 carbide ball used in chemical testing
2 OEM,ODM were accepted
3 ISO9001 certification
YG8 Tungsten Carbide Ball
Specification
1.Professionl manufacturer for tungsten carbide items with more than 12 years
2.ISO 9001-2008 Quality Control System
3.OEM, ODM project accepted
YG8 Tungsten Carbide Ball
Product Name |
Carbide balls/tungsten carbide steelball |
|
Specification |
Φ0.8mm—Φ80.0mm |
|
Grade |
YG8 |
|
Trademark |
YG6X/YG8/YG6/YG10 |
|
Feature |
hardness: 90-92 degrees hardness, density: 14.95 g/cm3, bending strength: 2750 N/mm2, excellent wear resistance and toughness. |
|
Applications |
Subtle bearings, precision sealing, measurement tools, squeeze the hole, stamping steel / brass stampings. |
|
Chemical composition |
WC |
Co |
92% |
8% |
|
Pictures show
Detailed grade information
Grade |
Density g/cm3 |
Hardness HRA(hv) |
T.R.S(M Pa) |
Performances &applications recommended |
YG6 |
14.9 |
89.5 |
2150 |
Good Wear resistance, used for hard wood,processing original wood, aluminum section bar,brass rod and cast iron. |
YG8 |
14.6 |
89 |
2320 |
Suitable for the roughening of cast iron and light alloys and also for the milling of cast iron and low-alloy steel. |
|
||||
|
Zhuzhou Tongda Cemented Carbide Works
Brief Introduction
Zhuzhou TongDa Cemented Carbide Works specialize in the production of bespoke Tungsten Carbide Hard Metal Wear Resistant Products for use across a wide range of industrial applications in both the as-sintered and finished ground condition.
Established in 2001 Zhuzhou TongDa Cemented Carbide Works are offering customers recommendations and solutions for individual wear resistant components and special tooling requirements.
Zhuzhou TongDa Cemented Carbide Works produce an extensive range of tungsten carbide grades in-house including the popular ISO application grades of K10, K20, K30, K40, P10, P20 & P30/40 as well as numerous special Cobalt and also Nickel binder tungsten carbide grades for use in corrosive resistant applications.
Material compositions including submicron, medium and coarse grain grades are available and can be supplied in cylindrical and flat section in both the as-sintered and finished ground condition.
The tungsten carbide grade powders are processed in-house using quality raw materials to ensure a high product quality is maintained. Individual items and volume production components can be produced by either pre-shaping or automatic press tooling.
Inhouse facilities include a comprehensive grinding shop plus EDM wire cutting and spark erosion as well as the capacity to offer tungsten carbide components mechanically retained into premachined steel housings and casings by interference fitting, induction & gas brazing or using adhesive bonding.
Producti show
Production Process
PRODUCTS RANGE
l Rods & Endmill
l Stripes & Plates
l cutting tools
l Ring & Roller
l Solutions for Polyolefins Industry
l Application in Coating Industry
l Wear parts of Concrete Pump
l Products for mining industry
l Other Customized Items
l Tungsten Heavy Alloy
Welcome to contact us for detailed information
Jana Wu
Sales Executive
TEL:0086-731-28161088
FAX: 0086-731-28161234
Website:
ADD: Xintangpo,Middle Hongqi Road, Hetang District, Zhuzhou City, Hunan Province, China
Last Update Time:2014-05-08
