Prefessoinal companies to provide integrated solution to 3d printing technology
Matched with most of the 3d printer in the market.
Can be workable with the size no smaller than 20*20*20cm objects
Mini 3d scanner ,which can be taken with you anywhere you go.
VGA Depth Image: 640 x 480 (VGA) [pixel x pixel]
Hot High precision MINGDA 3D scanner for cnc machine, latest 3D scanner Price
Description of mingda 3D scanner for cnc machine
This high precision 3D scanner has 3 cameras, the middle one is the RGB camera which is for capturing the pictures 640*480 ,30 frames of image per second at least, the other two on the different sides are depth sensor, the left one is the infrared emitter, the right one is the infrared receiver, which is for detecting the relative position of the object.
Features of mingda 3D scanner for cnc machine
1.Super anti-jamming capability( eg. easily deal with black hair, light fabrics and reflective surfaces )
2.Not need to mark on the scanned people and objects or spray imaging agent.
3.Not need auxiliary splicing tools, this 3D scanner is automatic splicing
4.High speed scanning ,real-time data to generate the three-dimensional data and files.
5.Large scanning range(Size of the scanned object is better larger than 20*20*20cm ),the scanned objects can be stuffed toys, statues, real people(no harm to body), machine parts ,automobiles, furniture and even the room layout.
6.Support 24-bit full-color scanning
7.Laptop scanning, more convenient
8.Not able for the mirror and the transparent objects
Description of MINGDA 3D printers
MINGDA new version 3D modeling machine series (Glitar 6C , Glitar 5C and Glitar 4C 3D Printer ) takes the leading in global area using 57 stepper motor, providing higher speed and stable performance compared with printers using 42 stepper motor. With high precision 32 subdivision main board, this printer machine makes less noise and works with much higher accuracy. The accuracy of XY/Z axis are separately up to1.0um and 1.5um, making it an ideal choice even for refined industrial products. It is compatible with ABS PLA Nylon Wood Filament material, and the max print size is up to 300x200x600mm. It is absolutely a perfect assistant for industrial model making and lowest 3D printer price .
Advantages for Mingda 3D printer
1. High-end stainless steel body and LED light, a sense of fashion and technology.
2. Enclosed chamber, insulating temperature, reducing external interference and warp of print.
3. 10mm in thickness, high temperature resistant aviation aluminum plate, heating equally; with high strength support base to keep the plate stable and leveled; no need calibration, easy to use
4. Big build volume 300*200*600mm
5.Fastened Z axis motor to make the layer thickness more precise, dual ball screw for Z axis on both sides.
6. 1.75mm extruder, suitable for more material.(Nozzle temperature can reach 260 degree)
7. Cooling fan above nozzle, making the PLA filament cool faster reducing filament pending.
Advantage of mingda 3D scanner for cnc machine
1. High Speed: The maximum scanning speed of up to 600000 points per second, XHCV portable 3D scanner ten times faster than ordinary scanner speed.
2. Large scan range: Can scan 1 cubic meters to tens of meters wide range of objects.
3. The scanning of moving objects: Because the portable 3D scanner and camera work similar, so it can not only scan the static objects, but also can scan dynamic objects. Especially suitable for obtaining medical human action and film production in the dynamic facial expressions.
4. Color 3D scanning: This portable 3D scanner can capture the bright colors (24 bit color), which can be scanned 3D shape and capture the object at the same time color.
Detail pictures about MINGDA 3D scanner for cnc machine
mingda handheld 3D scanner for 3D printer
Rotary table and stand for mingda 3D body scanner
3D printing work by mingda 3D scanner and 3D printer
Hardware parameters of mingda 3D scanner for 3D printer
Product dimension |
18cmx2.5cmx3.5cm |
Operating Temperature |
10-40 ℃ |
Data Interface |
USB 2.0 |
Operation Range |
350-1400 mm |
Spatial x/y Resolution @500mm |
1 mm |
Depth Z Resolution @500mm |
<1mm |
VGA Depth Image |
640 x 480 (VGA) [pixel x pixel] |
Maximal Frames-per-Second Rate |
30 FPS |
Power Supply |
USB 2.0 |
Maximal Power Consumption |
2.25 [Watt] |
Working environment |
Indoor and outdoor except the dark environment
|
Parameters of 3D printer manufacturer Mingda Glitar series mulitifunction 3D printer
MINGDA Company have 3 different kinds 3D printer china . The printing size is different . And the accuracy also is the different , Pls kindly check which printer will be most suitable for you .
Glitar 4C : 300*200*200mm
Glitar 5C : 300*200*400mm
Glitar 6C : 300*200*600mm
User Attention for mingda 3D scanner for 3D printer
In order to make high-performance of 3D scanner and ensure the normal running, your operating system should meet the following requirements:
1.Processor: Intel Processor, CPU should be higher than i5,recommend i7
2.Memory: 4G and larger than 4G
3.Transmission: Independent USD 2.0 transfer bus
4.Graphics: NIVIDA GT560,GT-710M,and support CUDA2.0 or
5.CUDA3.0 techniques recommended NIVIDA Geforce GT750 graphics card
Customers feedback for MINGDA 3D printer
1. Low noise: Balance connecting rod structure, 57 stepper motor makes less noise.
2. Perfect shape: Laser cutting seamless welding, superior stainless steel and stoving varnish, 4 arc round coener design, all in refined technology.
3. Easy to operate: SD card read directly or connected to PC, big LCD touch screen
4. High quality printing effect: full metal structure, 10mm thickness hot bed, dual ball screw all make printing effect more stable and with higher prrecision
5. Quickly and nice after-sale service: 1 year warranty, life long maintenance
MINGDA 3D Printer for 3d scanner also waiting for you
| Techical Parameters of MINGDA 3D Printer | ||||
| Model | Glitar 6S 3D printer | Glitar 6C 3D printer | Glitar 5C 3D printer | Glitar 4C 3D printer |
| Max printing size | 300*300*600 mm | 300*200*600 mm | 300*200*400 mm | 300*200*200 mm |
| Device dimension | 55*55*90cm | 53*41*85cm | 53*41*65cm | 53*41*50cm |
| Machine weight | 60kg | 50kg | 46kg | 38kg |
| Shipping weight | 75kg | 65kg | 58kg | 46kg |
| Size carton (cm) | 63*63*98cm | 63*49*92cm | 63*49*72cm | 63*49*60cm |
| CBM | 0.38CBM | 0.29CBM | 0.35CBM | 0.19CBM |
| Display&Controller | 3.2inch LCD touch screen | |||
| Layer thickness | 0.05-0.3mm | |||
| Filament | 1.75mm-PLA(recommend), ABS, Nylon,HIPS,PETG,flexible | |||
| Nozzle diameter | stand 0.4mm (0.2-1.0mm Available) | |||
| Printing speed | 0-200mm/s (Adjustable) | |||
| Positioning precision | Z:0.002mm, X/Y: 0.010mm | |||
| Print Technology | FDM (Fused Deposition Modeling) | |||
| Nozzle | 0-260 ℃ (Do not exceed 260) | |||
| Hot bed | 0-110 ℃(Adjustable) | |||
| Nozzle heating time | 1. 5 minutes | |||
| Hot bed heating time | 1 minutes | |||
| Interface | USB, SD card | |||
| AC Input | 95-265V, 56/60Hz | |||
| Machine power | 350W | |||
| File types | STL,G-Code | |||
| Operation software | Cura (SD card) | |||
| Operating system | Windows, Linux ,Mac OX | |||
| Frame Material | High-end Stainless Steel | |||
| Hot bed material | Aluminum | |||
| Ball screw | Dual Ball screw , diameter 16mm | |||
| Extruder | Single extruder (dual extruder available) | |||
| Language | Chinese/ English | |||
