Hot Sles Gold Mining Machine

Hot Sles Gold Mining Machine thumbnail-1
Hot Sles Gold Mining Machine photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
KATM
Model Number:
KATM-001
Contact Supplier Request Quote Chat Now
Shenzhen Keene Engineering Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name KATM
Model Number KATM-001

Specifications

This is a large capacity continuous cooling mercury recovery retort, designed to purify your mercury while separating it !

This is a large capacity continuous cooling mercury recovery retort, designed to purify your mercury while separating it from your gold.

The water chamber is 9 long, 4" tall and 2" wide with a 1/2" output port and a 1/2" input port .

The water chamber stands on 4" tall legs.

The vapor head is 1-1/2" wide by 1" deep and will hold a piece of amalgam about the size of a large lime.

This retort is designed to operate with water circulating continuously through the water chamber.  This prevents the water in the chamber from overheating and retort becoming vapor locked.

These retorts are designed to take a beating, they are made out of 1/8" thick mild steel, and all parts are welded.

All units are leak tested before they are painted with a rust resistant paint.

We have a five year warranty on all welds.   If the welding on the retort fails, we will repair or replace the retort with a new one.  You pay shipping one way.

What the box contains:

1ea) continuous cooling retort

2ea) 4' x 1/2" ID vinyl tubes

3ea) small hose clamps

1ea) 110V submersible pump

A complete set of instruction will be included in the box with the retort.


This retort may be operated as a single fill or continuous cooling method.
Single fill method:
Lay the retort on it's side, fill the cooling chamber with water by removing one end of the plastic tube, replace tube after filling with water.
Stand upright and load the vapor chamber.

Continuous cooling method:
Configure the retort to circulate water continuously through the cooling chamber by using the supplied submersible pump, hoses and clamps attached to the 1/2" supply and return tubes on the side of the retort, use a 5 gal bucket of water for better cooling and faster condensation during the mercury vaporization process.


Instructions for use.
Work in an open well ventilated area with a breeze at your back when operating the retort.  Have fire extinguisher at hand.
Caution!  DO NOT PUT THE PLASTIC TUBE IN THE WATER OF THE MERCURY RECOVERY CONTAINER during operation or cool down.
Attach the Pump discharge to one of the 1/2' tubes on the side of the retort, attach the other hose to the remaining tube and then place the pump and tube end into a 5 gal bucket full of water or ice water.  Start the pump.
Wrap and tie the mercury vapor filter (piece of cotton material) around the plastic tube to discharge the mercury into the water in the
recovery container to prevent mercury vapor escaping in the event your water becomes too hot during the distillation process.
Add your amalgam to the vaporizing chamber, seal with mud or product of your choice.
Heat vaporizer cap to cherry red, maintain until mercury stops dripping out the discharge tube.
Allow cap to cool before opening chamber.  After chamber is cool to the touch, remove mercury recovery container to a safe place for storage.
Leave a small amount of water to cover mercury during storage.
Detach hoses from retort and empty water from cooling chamber, then move retort to a small plastic tub to prevent any mercury from spilling on the floor while processing.

This is a large capacity continuous cooling mercury recovery retort, designed to purify your mercury while separating it from your gold.

The water chamber is 9 long, 4" tall and 2" wide with a 1/2" output port and a 1/2" input port .

The water chamber stands on 4" tall legs.

The vapor head is 1-1/2" wide by 1" deep and will hold a piece of amalgam about the size of a large lime.

This retort is designed to operate with water circulating continuously through the water chamber.  This prevents the water in the chamber from overheating and retort becoming vapor locked.

These retorts are designed to take a beating, they are made out of 1/8" thick mild steel, and all parts are welded.

All units are leak tested before they are painted with a rust resistant paint.

We have a five year warranty on all welds.   If the welding on the retort fails, we will repair or replace the retort with a new one.  You pay shipping one way.

What the box contains:

1ea) continuous cooling retort

2ea) 4' x 1/2" ID vinyl tubes

3ea) small hose clamps

1ea) 110V submersible pump

A complete set of instruction will be included in the box with the retort.


This retort may be operated as a single fill or continuous cooling method.
Single fill method:
Lay the retort on it's side, fill the cooling chamber with water by removing one end of the plastic tube, replace tube after filling with water.
Stand upright and load the vapor chamber.

Continuous cooling method:
Configure the retort to circulate water continuously through the cooling chamber by using the supplied submersible pump, hoses and clamps attached to the 1/2" supply and return tubes on the side of the retort, use a 5 gal bucket of water for better cooling and faster condensation during the mercury vaporization process.


Instructions for use.
Work in an open well ventilated area with a breeze at your back when operating the retort.  Have fire extinguisher at hand.
Caution!  DO NOT PUT THE PLASTIC TUBE IN THE WATER OF THE MERCURY RECOVERY CONTAINER during operation or cool down.
Attach the Pump discharge to one of the 1/2' tubes on the side of the retort, attach the other hose to the remaining tube and then place the pump and tube end into a 5 gal bucket full of water or ice water.  Start the pump.
Wrap and tie the mercury vapor filter (piece of cotton material) around the plastic tube to discharge the mercury into the water in the
recovery container to prevent mercury vapor escaping in the event your water becomes too hot during the distillation process.
Add your amalgam to the vaporizing chamber, seal with mud or product of your choice.
Heat vaporizer cap to cherry red, maintain until mercury stops dripping out the discharge tube.
Allow cap to cool before opening chamber.  After chamber is cool to the touch, remove mercury recovery container to a safe place for storage.
Leave a small amount of water to cover mercury during storage.
Detach hoses from retort and empty water from cooling chamber, then move retort to a small plastic tub to prevent any mercury from spilling on the floor while processing.
Recover your gold, then reseal chamber with cap to prevent any trapped mercury from spilling.
Recover your gold, then reseal chamber with cap to prevent any trapped mercury from spilling.
Hot sles Gold mining machineHot sles Gold mining machineHot sles Gold mining machineHot sles Gold mining machineHot sles Gold mining machineHot sles Gold mining machineHot sles Gold mining machine
