Cisco ME 3800X Series Carrier Ethernet Switch Router ME-3800X-24FS-M
Key Differentiators
Cisco Carrier Ethernet ASIC
Powered by Cisco’s Carrier Ethernet ASIC, designed specifically for the needs of service providers, the Cisco ME 3800X Series delivers essential Carrier Ethernet technologies including: Hierarchical QoS (H-QoS), MPLS, and Virtual Private LAN Services (VPLS). The ASIC provides line-rate performance and supports advanced services including access control list (ACL) and H-QoS without impacting performance. It incorporates innovative traffic management capabilities while providing intelligent packet switching and routing operations.
Service Richness
With the Cisco ME 3800X Series, each service is assigned enhanced QoS and security attributes. The Cisco ME 3800X Series accomplishes advanced per-traffic-class metering and offers bidirectional packets and bytes statistics. The service offering is enhanced with rich operations, administration, and management (OAM) functionality including: Layer 2 Connectivity Fault Management (CFM), IP SLA for Layer 3, and MPLS OAM.
Service Scale
The Cisco ME 3800X Series delivers unmatched service scalability in a 1RU footprint. With support for 256,000 MAC addresses and 8000 bridge domains, this switch router delivers high performance and high scale for point-to-point and multipoint VPN services. A total buffer size of 352 MB is available to provide per-service advanced QoS capabilities. Such an amount of buffer is required when stringent applications like financial services or video must be protected against the impact of a 10 Gbps to 1 Gbps speed mismatch. The quantity of statistical counters allows the Cisco ME 3800X Series to provide a high level of service metering and monitoring throughout its range of scale.
High-Performance Hardware
The Cisco ME 3800X Series provides two slots for hot-swappable and redundant power supply. Three fans are integrated into each power supply, providing fan redundancy. High availability is also achieved on the Cisco ME 3800X Series through proactive diagnostic tools including Generic On-Line Diagnostics (GOLD) and Onboard Failure Logging (OBFL). These tools help service providers avoid potential problems before they occur - and troubleshoot and diagnose once identified.
