Home > Products > Civil Engineer ( Lab Part ) > capacity ECONOMICAL SHENXIAN MANUAL CBR TEST MACHINE
capacity ECONOMICAL SHENXIAN MANUAL CBR TEST MACHINE
- 100 Piece / Pieces per Month
- Shanghai city in china
- Credit Card
Product Details
| Place of Origin: | Shanghai, China | Brand Name: | SX | Model Number: | CBR-A |
| Power: | Other, MANUAL | Usage: | Other, Soil Strength test in lab, do cbr test in civil engineer lab |
Product Description
Product Name : CBR TEST APPARATUS / CBR testing Machine / CBR Tester
Standard : MEETING ASTM , ISO and GB Standard
Applications:
The equipment consists one each of the following: load frame, Hand operated, Capacity 5000kg.
with high and low rates of travel of the lead screw.
Mould made from Gun0metal/Brass, 150mm internal dia. x 175mm high, with perforated base plate
and extensioncollar 50mm high. Penetration piston, face dia. 50mm with adjustable bracket for penetration dial gauge.
Circular metal space disc, 148mm dia. x 47.7mm high. With detachable handle.
Annular metal weight, 2.5k., 147mm dia. with 53mm dia.
central hole. Slotted metal weight, 2.5kg. 147mm dia. with 53 dia. slot. Perforated plate made of Gun-metal/Brass 148mm dia
. with adjustable stem and lock nut and a metal tripod for dial gauge. Cutting collar. Rammer 2.6kg
weight with drop of 310mm. Rammer 4.89kg. with drop of 450mm. Supplied proving ring and dial gauge.
