Home > Construction & Decoration > Construction Pipe & Tube > Copper Pipe & Tube > Mill Test Copper Pipe Sizes Chart for Machinery

Mill Test Copper Pipe Sizes Chart for Machinery

Mill Test Copper Pipe Sizes Chart for Machinery photo-1

Mill Test Copper Pipe Sizes Chart for Machinery photo-2

US$ 4,500 - 4,500 MOQ: 1 Metric Ton

Key Specifications

Get Latest Price

Type:

Straight Copper Pipe

Application:

Air Condition Or Refrigerator

Specification:

1/4''-4 1/4''

Contact Supplier Request Quote Chat Now

Shanghai Vast Link Industrial Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Type Straight Copper Pipe

Application Air Condition Or Refrigerator

Specification 1/4''-4 1/4''

Thickness 0.4-3.0mm

Length as your request

Cu (Min) 99.9%

Alloy Or Not Is Alloy

Wall Thickness 0.4-3.0mm

Outside Diameter 1/4''-4 1/4''

Model Number C12200,TP2

Place of Origin Shanghai, China

Product Description

Name:Copper Pipe

1.OD:1/4''-4 1/8''
2.WT:0.40-3.0mm
3.Length:as your requirement
4.High quality, good price, short delivery time

5.Standard: C12200,C11000...

6.Type:copper pipe

7.Shape:pipe

Product	Copper Pipe
Application	copper pipes are widely used in air-conditioning a nd refrigeration field service,heat exchange use, connecting tubes,distribution,fire protection,solar, natural gas,liquefied petroleum gas,vent piping.
Material	ASTM,JIS,EN...
Standard	C12200,C11000
Temper	soft annealed,special tempers on request
Outside Diameter	4.76mm to 28.58mm
Thickness	0.4mm to 3.0mm
Cu (Min)	99.90%
Alloy Or Not	Non-alloy
Cleanliness	all annealed coils meet or exceed the cleanliness levels specification.Coils are capper with plastic end caps.
Minimum Order Quantity	1MT
Loading port	SHANGHAI
Packing	Ends capped,in shrinking-wrapped bag,then into cardboard box
Length	Can be customized
Delivery Time	within 30 days after receicing the deposit
Payment Terms	L/C,T/T
Supply Ability	10000tons/year

Main Technical Parameters:

Standard size (Inch)
Standard	Copper Alloy No.	Chemical Composition		Mechanical Properties
Standard	Copper Alloy No.	CU%	P%	Temper	Tensile Strength (Mpa)	Elongation(%)	Grain Size (mm)
ASTM B88	C11000	99.90	-	60	200	-	0.040
	C11000	99.90	-	50	200	-	0.025
	C12200	99.90	0.015~0.040	H58	250	-	-
JIS H3300	C1100	99.90	0.015~0.040	O	205	40	-
				L	245~325	-	-
				H	265	-	-
	C1220	99.90	0.015~0.040	0	205	40	0.025~0.060
				L	205	40	0.040
				1/2H	245~325	-	-
				H	255	-	-
ASTM B75	C11000	99.90	-	60	205	-	0.040
	C11000	99.90	-	50	205	-	0.040
	C12200	99.90	0.015~0.040	H58	250	-	-
	C12200	99.90	0.015~0.040	H80	310	-	-
EN 1057		99.90	0.015~0.040	R220	220	40	-
				R250	250	30 OR 20	-
				R290	290	3

Packaging & Shipping

Company Information

Vast Link Industrial Co.,Ltd have a registered capital of US$ 50 million.
Our company is engaged in the production and trade of all kinds of copper pipe finished and unfinished products.copper Pipe is our main production and sell well. We have established business relationships with clients in the Korea, Japan, Singapore, Iran, Dubai, Yemen, Chile, Brazil, France, UK, Italy, Canada and more than 20 countries and regions for Stainless Steel Pipe Annual sales revenue is USD 50 billion. The details of payment method, delivery time and minimium quantity and so on for copper Pipe can be negotiated according to the order.
