Help CenterUV Quartz Glass Window
Related Products
Fused Silica Window
UV Fused Silica Windows are precision manufactured using UV-grade synthetic fused silica. In addition to superior transmission, the synthetic fused silica of these optical windows exhibit higher thermal properties, exceptional purity, and excellent environmental durability for demanding applications.
These optical windows are designed for use in optical systems to separate two environments while passing a particular spectral range between them. Applications include laser set-ups (i.e. at Brewster’s angle), emitter/detector protection devices (such as in spectrophotometers), and imaging systems involving ultraviolet wavelengths
Parameter
| Dimensional Tolerance (mm) | +0.00/-0.20 |
| Clear Aperture (%) | 90 |
| Thickness Tolerance (mm) | ±0.38 |
| Surface Flatness | 1λ |
| Surface Quality | 60-40 |
| Parallelism (arcmin) | 5 |
| Edges | Ground, Maximum 0.25mm Edge Chip |
| Coating | Uncoated |
| Substrate | Fused Silica |
| Type | Protective Window |
| Wavelength Range (nm) | 200 - 2200 |
Qinhuangdao Intrinsic Crystal Technology Co., Ltd has the advanced processing equipment and complete production system,which gurantees that we can effectively control every aspect of the product process, as well as product quality. It also has the advanatge to reducing losses and costs.
The High quality products are guarantee by Advanced testing equipment and methods
Packaging
Pay attention to every details of the package. According to the products, we choose the best suitable packaging.
Shipping
Many shipping methods to meet customer's demand.
