Home > Manufacturing & Processing Machinery > Cutting & Fold-bend Machine > Bending Machine > Hydraulic Automatic Steel Coils Up-ender Machine

Hydraulic Automatic Steel Coils Up-ender Machine

US$ 8,000 - 10,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Jiangsu, China

Brand Name:

Contact Supplier Request Quote Chat Now

Wuxi Bangzhou Machinery Manufacturing Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

ShangHai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Jiangsu, China

Brand Name BZ

Model Number Up-ender-5Ton

Machine Type Other

Raw Material Sheet / Plate Rolling

Material / Metal Processed Stainless Steel

Power Hydraulic

Automation Automatic

Extra Services Other

Certification ISO 9001:2000

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.up-ender machine is briefness and operate convenience ;
2.to make the stand coil lay on the table;
3.hydraulic control;

5T coil upender

Technical parameters:

Main technical parameters:

1. Load-bearing: 5T(max)

2. Rolled-diameter: 1600mm; height: 800mm

3. Diameter of rolled oil cylinder: φ125mm

4. Working pressure of hydraulic system: 0-16Mpa

5. Pump Motor Power: 4KW

6. Pump Type: CBT-F325

7. It is set independent hydraulic system and electrical system.

Other terms:

*Payment terms:Price: the whole line would be: $8000-10000 per set FOB SHANGHAI.

*Minimum Order Quantity:1 set/month

*Delivery time: 30-45 days per set after signing the contract

*Packing Terms: seaworthy packing

*Supply ability: 15sets/month

*Product warranty: one year warranty period

*Service promise: The supplier designs and makes the equipment with quality guarantee period of one year. The supplier will provide free maintenance within quality guarantee period, except the human mechanical fault, and only collect the part costs and the travel expense of the servicemen.
