Home > Electrical & Electronics > Telecommunication & Broadcasting > Fiber Optic Equipment > SENTER Brand OTDR ST3300/VFL Function/1310,1550NM/SM Fiber/EXFO OTDR

SENTER Brand OTDR ST3300/VFL Function/1310,1550NM/SM Fiber/EXFO OTDR

Name: SENTER Brand OTDR ST3300/VFL Function/1310,1550NM/SM Fiber/EXFO OTDR
Brand: Senter
SKU: 126631737

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Shandong, China

Brand Name:

Senter

Model Number:

ST3300

Contact Supplier Request Quote Chat Now

Shandong Senter Electronic Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shandong, China

Brand Name Senter

Model Number ST3300

I. Brief Introduction

As fiber optics plays more and more important role in modern telecommunication and CATV networks, the requirements to the construction, test and maintenance of fiber optics links also become more prominent.

ST3300 is a unique product mainly designed for construction and maintenance of telecommunication and CATV networks. ST3300 can be widely used in engineering construction,maintenance test and emergency repair of all fiber optics related systems. Comparing with a regular OTDR, ST3300 is more compact in size and easier for field use.

ST3300 has handheld design, compact and lightweight, easy to carry. Event information through TFT color display and data storage capabilities. Through the USB interface, the test data can be uploaded to the PC, to facilitate the post-processing, archiving and printing.

II. Main Features

-- Hand-held design, compact and lightweight;

-- Anti-seismic, shockproof and appropriate for field operation.

-- Unique hotkey design

-- Starting in 3 seconds measuring immediately

-- Narrow event blind zone, simple test of fiber patchcord

-- Automatic and manual test function

-- High Capacity SD card

-- Low-power design, optical lithium battery or AA-size alkaline batteries

-- Simple, fast, without complex training

-- VFL (Visual Fault Location) function

-- Multiple light outputs, FC/ST/SC exchangeable

-- OTDR Viewer software for data analysis

-- Light alarm function, preventing the device from being damaged by the signal light

III. Specification

Sub-Model	CuteOTDR-3300B	CuteOTDR-3300C
Wavelength	1310/1550
Sensing Fiber	Single mode fibers
Dynamic Range (dB)(1)	28/26	32/30
Pulse Duration(ns)	10ns/20/50/100/200/500/1000/2000/5000/10000/20000
Dead Zone(m) (2)	<3m(Reflective Event)
	<10m(Non-reflective Event)
Attenuation Detect Accuracy(dB/dB)	±0.05
loss Resolution(dB)	0.01
Sampling Resolution(m)	0.16-5
Distance Measure Accuracy(m) (3)	±(1m+5×10-5×distance+sampling space)
Max Measuring Distance (km)	1-120Km
Data Storage	>10000 records
Averaging Time	5s,15s,30s,1min,2min,3min
General Specifications
Dimensions(H×W×T)	21011267mm
Weight	1kg
Temperature	Operating Temperature 0°C-50°C
	Storage Temperature -20°C-60°C
Relative Humidity	0%-95%(non-condensing)
Battery life	>8 hours
Interface Type
Connector	FC(ST/SC Interchangeable)/PC
Connectivity	USB/SD card
Matching Function Modules
Visible Fault Locator	Wavelength: 650nm; Farthest distance test:5Km
Stable light Source Module(4)	Wavelength(±20):The work of OTDR with wavelength
Notes: (1) The dynamic range is SNR =1 the maximum pulse width within averaging time of 3 minutes (2) Conditions for dead zone measurement: reflection strength beleow-45dB, Event Dead Zone with 10ns pulses width measurement, Attention Dead Zone 50ns pulse width measurement. (3) Do not include due to refraction caused by the uncertainty. (4) Stable source and CuteOTDR sharing the same light port and Cute OTDR work wavelength consistent.
