SENTER ST3200 Fttx palm OTDR meter with VFL SM OTDR 32/20dB
ST3200 OTDR (Optical Time Domain Reflectometer) is an intelligent optical fiber communication tester. This tester is easy to use and portable, which has a 3.5-inch color LCD touching screen. It also possesses events intelligent analysis and more user—friendly operation.
It is an ideal test instrument for the fiber testing and troubleshooting. It can test the length of optical fiber and optical fiber cable attenuation coefficient. It can exactly display the loss distribution curve of the optical fiber and cable as well as the loss between two points and the joint loss. It also can test the distance between two points and the position of joint, fault point as well as breaking point. This tester has VFL (Vision Fault Locating) system. So it becomes convenient to test the fault location of jumper wire.
Main functions
Test the distance between two points and dynamically display the distance between two cursors
Test the loss between two points and the loss constant of the optical fiber and cable
Test the joint loss
Auto-optimization and quick response
Search for the event points automatically
The function of wave form storage: it can store the wave form data and test condition into the disk and the stored information also can display again.
Support the function of copy: it can copy the data file which is built in the internal disk into the U-disk directly.
Specifications SENTER ST3200 Fttx palm OTDR meter with VFL SM OTDR 32/20dB
General Specifications | |||
Optical output connector |
FC-PC (standard) |
||
Display screen |
320×240 3.5 inch colored LCD (touch screen) |
||
Port |
USB port |
||
Environmental requirement |
Working environmenttemperature: 0~50℃ Storing environmenttemperature: -20~60℃ Relative humidity: 0%~95% (non-condensing) |
||
Dimension |
D×W×H: 220mm×105mm×60mm |
||
Weight: |
about 1 kg |
||
Duration of the battery |
Standby: >50h Testing Time: >20h |
||
Key Tech Specifications | |||
Sub Models |
ST3200-3528 |
ST3200-3532 |
|
Wavelengths |
1310nm/1550nm±20nm |
||
Dynamic Range |
28/26dB |
32/30dB |
|
Range(km) |
1, 2, 4, 8, 15, 30, 60, 90, 120 |
1, 2, 4, 8, 15, 30, 60, 90, 160 |
|
Fiber Under Test |
single mode |
||
Pulse Width(ns) |
10/20/50/100/200/500/1us/2us/5us/10us/20us/Auto |
||
Working Current |
450-600mA |
||
Power Consumption |
About 4 W |
||
Event Dead Zone |
≤2m |
||
Attenuation Dead Zone |
≤10m |
||
The VFL output power |
>2mW |
||
The capacity of storing waveform |
>10000 |
||
±0.05 |
|||
Loss Threshold(dB) |
0.01 |
||
Loss Resolution(dB) |
0.01 |
||
Sampling Resolution(m) |
0.16~5 |
||
Averaging Time |
5s, 15s, 30s, 1min, 2min, 3min |
||
Power Consumption |
<3W |
||
Alarm with light |
>1uw(-30dbm) |
||
Distance Uncertainty |
±(1m+sampling interval + range×0.005%) |
||
Compositions of the tester
Basic composition
Items |
Names |
Quantity |
host |
ST3200 OTDR |
1 |
Standard accessory |
Battery charger |
1 |
User manual |
1 |
|
CD (including ST3200 imitated analysis software) |
1 |
|
USB Data Cable |
1 |
|
Carrying Bag |
1 |
Optional modules
Order numbers |
Operating wavelength |
Type of the testable optical fiber |
Dynamic range (SNR=1) |
ST3200-3528 |
1310nm/1550nm ±20nm |
SMF single mode |
28/26dB |
ST3200-3532 |
1310nm/1550nm ±20nm |
SMF single mode |
32/30dB |
Options
NO. |
Names |
Type and specification |
Specification |
1 |
SC |
Adapter |
|
2 |
ST |
Adapter |
Shandong Senter Electronic Co., Ltd., located in state-level New & Hi-Tech development zone of Zibo city, is a high technology enterprise applying itself to provide communication test instruments and comprehensive network monitoring solutions. It was founded in1996, there are 160 staffs now, 20 million RMB registered capital, Senter covers an area of 20,000 square meters.
Senter have passed the ISO9001 international quality management system certification, now is the “High Technology Enterprise”, “Software Enterprise ”, “Center for Post-doctoral studies ”, “Zibo Communication Maintenance Instruments Engineering Technology Research Center ” and “The national Intellectual Property Pilot Units”, and has the honor to get “Shandong Provincial Outstanding Private Science and Technology Enterprise”, “China's Patent Shandong Star Enterprise”, Senter have six functional departments and two business divisions, and have New technology R&D center in Shenzhen.
