Specifications
PLC control and hydraulic system337kw cummins engine
CE certificate
dredging depth 10m
discharge distance 800m
the main dimensions of the 8inch cutter suction dredger
Dredge Unit |
|
A.Principal Dimensions |
|
(1)Length overall |
22 m |
(2)Breadth |
5.2 m |
(3)Depth |
1.8 m |
(4)Draft loaded |
1.3 m |
B.Main Pontoon |
|
(1)Length |
10m |
(2)Width |
2.2 m |
(3)Depth |
1.8 m |
(4)Plate thickness- sides |
6 mm |
(5)Plate thickness- front and rear sides |
12 mm, 12 mm |
(6)Plate thickness- Deck |
5 mm |
(7)Plate thickness- Bottom |
8mm |
C.Side Pontoons |
|
(1)Length |
16 m |
(2)Width |
1.5 m |
(3)Depth |
1.8 m |
(4)Plate thickness- sides |
6 mm |
(5)Plate thickness- Deck |
5 mm |
(6)Plate thickness- Bottom |
8 mm |
Warranty of dredger
1) 12 months manufacturing warranty on all new installed component parts.
2) 12 months warranty on the diesel engines, generators, gear boxes, dredge pumps, Hydraulic system,
Electrical system, control system.
3) 12 months warranty on hull and all fabricated parts.
Tools :A complete set of daily tools will be supplied with the dredger for assembly
and to carry out all major overhauls, including specialists service tools
the cutter suction dredgre working in the project site
