Specifications
1.suction dredger for sale in stock2.testing center for ex-factory
3.Cummins engine
4.train operating
Shengjie Cutter Suction Dredger
1. Design
Our cutter suction desilting dredgers are designed by senior engineer, who have specialized in shipbuilding and dredging work for many years, to guarantee they are well-designed and practical.
2. Skilled workers & ex-work testing
Every cutter suction desilting dredger is built by skilled workers and inspected strictly to assure the high quality and durability. Each finished dredger will be tested in our testing center to make sure it works smoothly when delivering to customers.
3.Cummins Engine
The desilting dredgers are equipped with world famous powerful Cummins engine, which are famous for its durability, lower oil consumption, standardized accessories and easy maintenance.
4. Hydraulic system
Hydraulic system: the most important parts of cutter suction desilting dredger. The hydraulic system requirements are very high and strict; it’s the main artery of the entire dredger. Lateral traction winches, lifting winch and cutter head of the dredgers are driven by hydraulic motors.
An integral hydraulic system includes hydraulic oil tanks, hydraulic pump, hydraulic valve manifold, solenoid valve, hydraulic pipes, hydraulic components, electrical actuator and so on.
5. Detachable Structure
The cutter suction desilting dredgers are detachable, so it is easy to transport when delivering or moving from one working site to another.
6. Assembly & Staff Training
Our experienced installers will arrive at the construction site to guide, teach and training your staff to debug and operate the desilting dredger until they can operate skillfully by themselves.
Technical specification list for your reference
| Model | SJCSD350 Cutter Suction Dredger |
| Hull length*hull width*hull depth | 24*7.5*2m |
| Max. dredging depth | 18m |
| Discharge distance | 2000m |
| Load draught | 1.3m |
| Diameter of suction pipe | 500mm |
| Diameter of discharge pipe | 500mm |
| Diameter of cutter head | 900mm |
| Productivity | 600m3/h |
| Water flow | 3000m3/h |
| Main engine power | 882kw |
| Shaft power of cutter | 120kw |
| Diameter of spuds | 530mm |
| Thickness of spuds | 20mm |
| Genset power | 30kw |
| Max. oil consumption | 0.2g/KW.h |
| Structure | Can be dismantle and assemble at working site |
Our Service:
1. Reply your inquiry in 24 working hours.
2. Experienced staffs answer all your question in professional and fluent English.
3. Customized design is available.
4. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staffs.
