factory supplier hzs60 ready-mixed concrete mixing plant
Product Range Click below to choose your desired product categories
Concrete Batching Plant |
Stabilized Soil Mixing Plant |
Lime Digestion Machine |
Cutter Suction Dredger |
Model |
HZS60 ready-mixed concrete mixing plant |
Rated productivity |
60m3/h ready-mixed concrete mixing plant |
Batching machine type |
PLD1600 |
Mixing engine |
JS1000 |
Max. aggregate diameter |
80/60mm |
Motor power |
37kw |
Model |
Belt Type |
Aggregate bin |
12m3/single bin |
Aggregate metering accuracy |
±2% |
hopper volume |
2m3 |
powder metering accuracy |
±1% |
powder metering range |
10-600kg |
Water metering |
±1% |
Total power |
96Kw |
Total weight |
22T |
Floor Area(L*W) |
42×16(m) |
Discharging height |
3.8 m |
Silo (optional-parts) |
100T/Φ2900 |
Manual Butterfly Valve |
D250 |
| 1 | HZS series concrete batching plant consists of aggregate batching system, concrete mixing system, cement supply system, water supply system, cement weighing system, water weighing system, control system, etc. |
| 2 | All aggregates are fed into the aggregate batching machine by loader, and weighed in the weighing hopper or weighing belt. After weighing, they are transported to a hopper or a belt, and then the aggregates are transported to the mixer for mixing. |
| 3 | Cement is conveyed into the cement weighing hopper by screw conveyor for weighing, after weighing, cement is poured into mixer. |
4 |
Water is pumped into water weighing hopper by water pump. After weighing, water is sent into the mixer. |
| 5 | After all materials are weighed and fed into the mixer, the mixer can begin to mix and produce concrete. |
