Bevelled Glass

Negotiable MOQ: 25 Metric Tons (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

Model Number:

kj-0019

Shouguang Kejing Glass Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name kj

Model Number kj-0019

Function Decorative Glass

Shape Flat

Structure Solid

Technique Clear Glass

Type Float Glass

Specifications

Glass with bevelled edge
1,Excellent mechanical strength
2,safety performance
3,Not easily broken.

Beveled glass panel:

1) polished edges processing

2) tempered/ toughened

3) silkscreen

4) More size and shape

Beveled glass specification:

Beveled glass width from 5mm to 48 mm (From 0.2 Inch to 2 Inch)
Customized size and design available
Shape: regular square, rectangle, circle shape, irregular shape
Regular size: 400x600mm, 600x800mm, 700x900mm, 500x500mm, 1000x1500mm, etc.
Size tolerance: +/- 1.00mm.
Minimum grinding size: 100*100mm,
Packing: large beveled glass sheet is packed by wooden crate. The small glass sheet is packed by soft plastic foam being interleaved between each piece of glass, outside packed by strong wooden crate, suitable for long time ocean transportation.

Quality standard: CE, ISO9001, IKEA test report

NO.	NOVAL Beveled mirror quality standard				Grade A
1	Spot fault such as bubble or smear	< 0.4 mm			Permissible
		0.4 - 0.5 mm		Within 20cm from sides of Big-sized Mirror Within 15cm from sides of Middle-sized Mirror Within 8cm from sides of Small-sized Mirror	Permissible up to B 2 M 1 S 0
		> 0.50mm			Not Permissible
2	Scratch	Width ≤0.1mm Length ≤50mm		Same position above	Permissible up to B 4 M 2 S 1
3	Edge Loss				Not permissible
4	Rough Particle				Not permissible
5	Scalloping on Bore Edge (No effect on safety and installation)				≤3 mm
6	Missing grinding		5%Perimeter of Big-sized Mirror 2%Perimeter of Middle-sized Mirror Not permissible on Small-sized and Model Mirror		B 2 M 1 S 0
7	Stain				Not permissible
8	Ripple and Color Bottom				Not permissible when straight eye-inspection
9	Grinding Trace				Not permissible
10	Transparent Spot				Not permissible
1 1	Shell				≤0.3mm
12	Scratches in grooves				2lines width ≤0.3mm / 0,5 m

13	Irregular cloudy on etching structure surface				Not permissible when straight eye-inspection
14	Hanger Position Tolerance Note: Glue should be neutral and vertical strip on hanger				≤3 mm
15	Note: Forbid to clean lacquer with corrosive cleaner abluent. (e.g. acidic or alkaline liquid)				Not permissible
