Dahua 3Mp IPC-HDBW4300E-AS IP mini dome network camera DH-IPC-HDBW4300E-AS POE / Micro SD storage/Audio 1/1 channel In/Out
Overview
>1/3” 3Megapixel progressive scan CMOS
>H.264&MJPEG dual-stream encoding
>Max 20fps3M(2052×1536), 25/30fps1080P(1920×1080)
>DWDR, Day/Night(ICR), 3DNR,AWB,AGC,BLC
>Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
>3.6mm fixed lens (2.8mm optional)
>Max. IR LEDs Length 30m
>IP66, IK10, PoE
>Audio 1/1 channel In/Out
>Alarm 1/1 channel In/Out
>Micro SD Max 64GB
SPECIFICATION
| Model | IPC-HDBW4300E-AS | |
| Camera | ||
| Image Sensor | 1/3” 3Megapixel progressive scan CMOS | |
| Effective Pixels | 2052(H)x1536(V) | |
| Scanning System | Progressive | |
| Electronic Shutter Speed | Auto/Manual, 1/3(4)~1/10000s | |
| Min. Illumination | 0. 1Lux/F1.2 (Color), 0.01Lux/F1.2(B/W);0Lux/F1.2(IR on) | |
| S/N Ratio | More than 50dB | |
| Video Output | N/A | |
| Camera Features | ||
| Max. IR LEDs Length | 30m | |
| Day/Night | Auto(ICR)/Color/B/W | |
| Backlight Compensation | BLC / HLC / DWDR | |
| White Balance | Auto/Manual | |
| Gain Control | Auto/Manual | |
| Noise Reduction | 3D | |
| Privacy Masking | Up to 4 areas | |
| Lens | ||
| Focal Length | 3.6mm (2.8mm optional) | |
| Max Aperture | F1.8(F2.0/F1.8) | |
| Focus Control | Manual | |
| Angle of View | H: 72.5°/90°/44° | |
| Lens Type | Fixed lens | |
| Mount Type | Board-in Type | |
| Video | ||
| Compression | H.264/ MJPEG | |
| Resolution | 3M(2052×1536)/1080P(1920×1080) / 720P(1280×720) / D1(704×576/704×480) /CIF(352×288/352×240) |
|
| Frame Rate | Main Stream | 3M(1~20fps)/ 1080P/720P(1 ~ 25/30fps) |
| Sub Stream | D1/CIF(1 ~ 25/30fps) | |
| Bit Rate | H.264: 32K ~ 8192Kbps | |
| Audio | ||
| Compression | G.711a/G.711u/PCM | |
| Interface | 1/1 channel In/Out | |
| Network | ||
| Ethernet | RJ-45 (10/100Base-T) | |
| Wi-Fi | N/A | |
| Protocol | IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour | |
| ONVIF | ONVIF Profile S | |
| Max. User Access | 20 users | |
| Smart Phone | iPhone, iPad, Android, Windows Phone | |
| Auxiliary Interface | ||
| Memory Slot | Micro SD Max 64GB | |
| RS485 | N/A | |
| Alarm | 1/1 channel In/Out | |
| PIR Sensor Range | N/A | |
| General | ||
| Power Supply | DC12V, PoE (802.3af) | |
| Power Consumption | Max 4W | |
| Working Environment | -20°C~+60°C, Less than 95% RH | |
| Ingress Protection | IP66 | |
| Vandal Resistance | IK10 | |
| Dimensions | Φ110mm×81mm | |
| Weight | 0.29kg | |
DIMENSION
COMPANY INFORMATION
Dahua Technology is a world-leading and advanced video surveillance solution provider. The company’s product portfolios include the advanced series of front-end, back-end, display, software as well as intelligent traffic solution. Dahua was the first company in China to launch 8-channel real-time embedded digital video recorder in 2001. Since then, the company keeps on investing and building strong R&D capabilities for new technology and innovation. With nearly investing 10% of sales revenue every year, Dahua has a more than 3000 professionals in R&D team, aiming to provide the cutting edge products with high quality and performance. To create win-win situation and to maximize customers’ values are always our priorities.
Dahua has established sales, marketing and service network locally and globally. Asides offices in mainland China, the company also has offices or sales representatives in Asia, the Americas, Europe, Oceania, Africa and others, responding to the market with the best service and products. Meanwhile, Dahua provides the industry leading “three-year” warranty in China’s market. To-date, Dahua’s products are widely applied in many fields, such as banking, public security, energy, telecommunication, intelligent-building and intelligent-transportation. Numerous major projects have been installed with Dahua’s solutions, for example, the Three Gorges Hydropower Plant, Six-Country Summit, Olympic Venues, Shanghai World Expo, UNESCO site in Italy and London Underground as well as many others.
Dahua Technology owns 442 patents, including 20 invention patents. In China, Dahua Technology is a Safety City project recommended brand and one of China’s most influential security companies. At international front, the company has been awarding “Top 10 Security Brand in China” for 9 years and has been ranking in “Security 50” by a&s magazine for 8 years. Moreover, Dahua enjoyed 2nd largest market share according to IMS global report 2014.
