automatically switching electric valve actuator
Summary
The electric actuators we manufactured are the products by using the introduced advanced technology from Europe advanced technology.
It has various kinds of protection function and control mode. It can be divided into the part-turn series, linear-turn series and multi- turn series. There are more than hundred kinds of specifications. Its control main board is continuously upgrading and updating and the new products appear rapidly in order to satisfy the needs of modern industrialization.
The electric actuator has already widely applied in the large and medium-sized project which is the newly built and was highly appraised by users.
At the same time, we also accumulate rich technology and scene experiences in the process of updating and upgrading DKJ or other actuators to the introduced series.
The operator can realize the field control, remote programming, function combination, on-line monitoring, fault analysis,operation maintenance in the control room.
It is more advanced, convenience, and reliable
Demonstration: OA-10/ voltage travel time mounted model control model
Supply voltage: K: 220VAC, F: 380VAC,
Travel time: Sees the table
Mounted model: Z: Direct-mounted, H: foot-plate,
Control model:L: Two types, switch, switch quantity input, abbreviation: Integral-model and proportional modulating type,4---20mA input
S: Separated-model and proportional modulating type, 4---20mA input
Y: Remote-control type, the switch quantity input
Part-turn
|
type
|
BELL series type (with liquid crystal display) |
Torque Nm |
Travel time S/90degree |
Rated output |
OA-10 |
BELL-10 |
150 |
25 |
0.025 |
AS-25 |
BELL-25 |
250 |
30 |
0.065 |
BS-60 |
BELL-60 |
600 |
30 |
0.16 |
A+RS100 |
BELL-100 |
1000 |
48 |
0.25 |
B+RS160 |
BELL-160 |
1600 |
40 |
0.25,0.4 |
B+RS250 |
BELL-250 |
2500 |
40 |
0.65,0.4 |
B+RS400 |
BELL-400 |
4000 |
65 |
0.4,0.65,1.0 |
B+RS600 |
BELL-600 |
6000 |
105 |
0.4,0.65,1.0 |
B+RS800 |
BELL-800 |
10000 |
105 |
1.0 |
