Manual Override Butterfly Valve

Name: Manual Override Butterfly Valve
Brand: BELL
SKU: 126579609

US$ 50 - 2,000 MOQ: 1 Set

Key Specifications

Standard or Nonstandard:

Standard

Structure:

Butterfly

Pressure:

Low Pressure

Tianjin Bell Automatic Instrument Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin port China or according to request

Delivery Detail:

Delivery time depends on order quantity.

Standard or Nonstandard Standard

Structure Butterfly

Pressure Low Pressure

Power Manual

Material Other, Stainless Steel, Iron

Temperature of Media Normal Temperature

Media Water

Port Size 1 1/2"-40"

Place of Origin Tianjin, China

Model Number bell

Brand Name BELL

Specifications

1.Nominal Diameter:1-1/2"-12"
2.Pressure Grade:1.0/1.6 MPa
3.Manual override Butterfly Valve
4.ISO

Manual override Butterfly Valve

Cast steel Manual-operated Wafer Butterfly Valve Manufacturers

Manual-operated Wafer Butterfly Valve Manufacturers

Type: D7A1X-10, D7A1X-16

D7L1X-10, D7L1X-16

Parameters of Manual-operated Wafer Butterfly Valve

Nominal Diameter	1-1/2"-12" (DN40-DN300)
Pressure Grade	1.0/1.6 MPa
Operating Temperature Range	-15~150 °C/ Degrees Celsius
Suitable Mediums	Freshwater,sewage,seawater,air,steam,food,medicine,various kind of oils,acids,alkali and salt
Features	1.small-size,convenient,easy to assemble and disassemble,maintenance,fix at any positions 2.simple-structure,compact,quick 90 degrees on-off operation, small operating torque, light and handy 3.more than ten thousand times of on-off experiment, longer operating life 4.almost linear flow characterstic,better regulating performance 5.full sealed, zero gas leakage 6.different materials in every parts, suitable to different mediums
