TurkeyTundish Refractory Slide Nozzle (LQTN)

TurkeyTundish Refractory Slide Nozzle (LQTN) thumbnail-1
TurkeyTundish Refractory Slide Nozzle (LQTN) thumbnail-2
TurkeyTundish Refractory Slide Nozzle (LQTN) photo-1
TurkeyTundish Refractory Slide Nozzle (LQTN) photo-2
Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Shape:
Pipe
Material:
Alumina Block
Contact Supplier Request Quote Chat Now
Jinan Linquan Import And Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Shape Pipe
Material Alumina Block
Al2O3 Content (%) ≥ 85%
Model Number LQTN
Brand Name Linquan, Emei, Siwei, lqtrade

Specifications

1:TurkeyTundish refractory slide nozzle
2:Alumina quality.
3:High refractoriness.
4:Timely delivery.



LQ-Serise Tundish(Pouring box) Nozzle Refractory



Product Description





 TurkeyTundish refractory slide nozzle (LQTN) is detailed as follow :

Linquan manufactures a wide range of slide gate plate refractories for various international systems.A range of High Alumina fired, Alumina Spinnel fired, Alumina Carbon fired Inner and Outer Nozzles are manufactured as per the requirements of the slide gate system.







1. Tundish Nozzle



Chemical and Physical Properties

LQTN-

AlC75

LQTN-

AlC80

LQTN-

Al75

LQTN-

Zr96

LQTN-

Zr65

Al2O3    ≥ %

75

80

94

-85

-

ZrO2    ≥     %

-

-

-

(Insert)

 92-96

65

C    ≥   %

4

4

-

-

-

Apparent porosity  ≤

8

7

15

9

20

Bulk density  g/cm3   ≥

2.90

2.95

2.95

3.05

3.5

Compressive strength (MPa) ≥

60

60

120

80

-

High temperature bending

strength (MPa) (1400*0.5h) MPa ; ≥

6

7

15

20

-







2. Preassembled slide plate and lower nozzles







Chemical and Physical Properties

LQPSPL-80

LQPSPL-90

LQPSPL-Mg90

LQPSPL-94

LQPSPL-55

LQPSPL-Zr

Al2O3    ≥ %

80

90

-

94

55

80

MgO   ≥  %

12

-

90

-

8

ZrO2≥3

C     ≥  %

-

-

-

-

8

3

Apparent porosity ≤%

15

15

16

18

10

9

Bulk density g/cm3  ≥%

3.0

3.1

2.9

3.0

2.9

3.1

Compressive strength (MPa)

80

100

100

85

-

-











*Zirconia insert



Chemical and Physical Properties

LQZr60

LQZr70

LQZr80

LQZr85

LQZr95

ZrO2    ≥     %

60

70

80

90

95

Apparent porosity  ≤

21

20

18

15

6

Bulk density  g/cm3   ≥

3.70

3.90

4.0

4.35

5.2

Refractories  ≥  C

1800

1800

1850

1900

1900







Jinan Linquan provide a very wide range of Tundish Nozzles used for controlling the flow of steel from the Tundish to the Continuous Casting equipment including:
*Zirconia/ Zircon Nozzles – Manufactured in 65% to 95% Zirconia.
*Isostatically Pressed Nozzles – made in Alumina Carbon quality for medium and small steel plants.







1) Serivice life depends on steel-making condition, refractory slide gate and different operation mode.



2) For composited slide plate, we can mark different material in different part and detailed index according to the drawings.



3) Delivery time depends on the drawings. If new moulds are needed, an additive period may be necessary. In general it is 35-50 days.







Packaging & Shipping
