All in One Design 30W Solar LED Lamp Post Lights

All in One Design 30W Solar LED Lamp Post Lights photo-1
All in One Design 30W Solar LED Lamp Post Lights photo-2
All in One Design 30W Solar LED Lamp Post Lights photo-3
All in One Design 30W Solar LED Lamp Post Lights photo-4
All in One Design 30W Solar LED Lamp Post Lights photo-5
All in One Design 30W Solar LED Lamp Post Lights photo-6
US$ 420 - 500 MOQ: 10 Units
Key Specifications
Get Latest Price
LED Light Source:
30
Input Voltage(V):
12
Lamp Power(W):
30
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI/SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.
LED Light Source 30
Input Voltage(V) 12
Lamp Power(W) 30
Lamp Luminous Flux(lm) 3300
Lamp Luminous Efficiency(lm/w) 110
Color Temperature(CCT) Pure White
Working Temperature(℃) -30, 60
Working Lifetime(Hour) 50000
Lamp Body Material Aluminum Alloy
IP Rating IP65
Certification CE
Warranty(Year) 2
Place of Origin Shandong, China
Brand Name LINQUAN
Model Number LQSTY-230

All in one design 30W Solar LED Lamp Post Lights



We accept customized mounting methods according to clients' project requirement:

Wall mounting-

 All in one design 30W Solar LED Lamp Post Lights All in one design 30W Solar LED Lamp Post Lights



Scew fixing mounting-

All in one design 30W Solar LED Lamp Post LightsAll in one design 30W Solar LED Lamp Post Lights



Tube mounting-

All in one design 30W Solar LED Lamp Post LightsAll in one design 30W Solar LED Lamp Post Lights



Specification data for All in one design 30W Solar LED Lamp Post Lights:

All in one design 30W Solar LED Lamp Post Lights





We offer customized solution to meet clients' different project and budget requirement:

1. Customized shell material:
High quality Aluminum alloy frame, light weight, anti-corrosion and visual good looking;
Galvanized iron frame, lower cost to reduce total budget, 3 -years corrosion resistance guarantee. Accept customized shell color.

2. Customized working method
Motion sensor, LED full power lighting when there is people/vehicle passing-by, LED 1/3 power
lighting when there is no people/vehicle passing. Induction time: 60s, sensing distance: 9-10m.

Timing control: Customize time period for different working power.
Recommended"3+4+5", first 3 hrs full power lighting, second 4 hrs 1/2 power lighting, last 5 hrs 1/3 power lighting.

3. Customized brand of components:
Solar panel: USA SUNPOWER brand solar panel(19-23% efficiency) or normal monocrystalline solar panel(17-18% efficiency).
LED lamp: High quality USA bridgelux LED chip or TAIWAN EPISTAR LED chip
Customzied color temperature (2700-6500K) upon request.

Lithium battery with 5 years life time guarantee, accept customized capacity to increase lighting time or reduce product cost.

4. Accept OEM logo printing

(Qty above 50 units free of charge).

5. Mounting method: Screw and bracket fixing or Mounting tube



Project reference: 25W/30W LED All in one integrated solar LED street lights, without built-in solar panel, suitable for existing solar light with PV 100W-120W:

All in one design 30W Solar LED Lamp Post Lights

Optional High efficiency USA SUNPOWER OR GERMANY BOSCH solar panel for All in one design 30W Solar LED Lamp Post Lights:

All in one design 30W Solar LED Lamp Post LightsAll in one design 30W Solar LED Lamp Post Lights

Galvanized Iron Shell All in one design 30W Solar LED Lamp Post Lights:

All in one design 30W Solar LED Lamp Post Lights



Mounting tube for 50mm pipe:

All in one design 30W Solar LED Lamp Post Lights



Standard Model: All in one design 30W Solar LED Lamp Post Lights:

All in one design 30W Solar LED Lamp Post LightsAll in one design 30W Solar LED Lamp Post LightsAll in one design 30W Solar LED Lamp Post Lights
