Home > Construction & Decoration > Wire Mesh > Stainless Steel Wire Mesh > Mesh With Pvc in Back, 1000*1000, 12*12
Mesh With Pvc in Back, 1000*1000, 12*12
Negotiable
MOQ: 20 Rolls (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
FUXING
Material:
Other, 100% Polyester
Type:
Other, Mesh Fabric
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Brand Name
FUXING
Material
Other, 100% Polyester
Type
Other, Mesh Fabric
| Technical Data Sheet | |||
| mesh 1000*1000, 12*12 with pvc in back | |||
| Features: | |||
| l Excellently compatible with various Solvent based digital printers | |||
| l Perfect printing impression with stable ink absorption and faster drying ability | |||
| l Good physical strength in longitude and latitude | |||
| l Anti-age and weather resistance performance | |||
| l Special hole size suitable for windy area application, and especially good for super | |||
| wide Billboard outside | |||
| l Easy transportation, handling and installation | |||
| Description | |||
| l Knit fabric: 1000 denier low shrinkage, high strength yarn. | |||
| l PVC film: E-PVC | |||
| l Plasticizer: DINP | |||
| l Width: 1.60/2.50/3.20m | |||
| l Length: 50m | |||
| l Shelf Life: Up to 1 year at 20°C and relative humidity of 50% | |||
| l Durability: Up to 1 year | |||
| Physical Characters | |||
| properties | units | Test method | Average value |
| Base Fabric Yarn | Denier | 1000DX1000D | |
| Base Fabric Density | Thread/inch | FZ/T01003 | 12*12 |
| Finished Fabric Weight | Gram/m2 | FZ/T01003 | 270±20 |
| Thickness-finished product | mm | GB/T6672-2001 | 0.32±0.05 |
| Tensile strength at MD | N/5cm | GB/T1040 | 1300min |
| Tensile strength at CD | N/5cm | GB/T1040 | 1300min |
| Elongation at break MD | % | GB/T1040 | 22min |
| Elongation at break CD | % | GB/T1040 | 25min |
| Tearing Strength at MD | N/5cm | GB/T16578 | 120min |
| Tearing Strength at CD | N/5cm | GB/T16578 | 140min |
| White Degree | GB/T2913 | 80±5 | |
| Minimum appilcation temperature | .C | 0 | |
| Temperature range | .C | -20~+70 | |
| Flame retardancy | Self-extinguishing | ||
