Supply Minco MB8 Auto Synchronizing Parallel System/Panel
1. Minco MB8 Auto Synchronizing Parallel System/ Auto Synchronizing Parallel Panel has auto synchronous or asynchronous synchronizing multi gensets function
2.Auto start, automatical synchronize and share the loading
3.Parallel power can be customized
MB8 can start up and synchronize the generating sets automatically in case the mains is abnormal or unavailable. It can also analyzes the loading characteristic and shares the loading amongs the generating sets. When the mains restores normal, the generating sets will be phased out automatically and sequentially. This would avoid a lot of manual errors.
1. Automatic control single genset, exactly match the bare generator.
2. Large screen backlight character LCD display,genset status highlighting show;
3.Automatic start, automatica synchronize the generating sets, automatic load distribution adjustment, automatic separate and stop genset.
4.Chinese and English menu, interactive operation. Can be set and operated without computer.
5. Direct character display alarm details and working state,more than 50 fault records
Standard configuration:( Electronic Governor, synchronization AVR)
9 inch standard cabinet : 600*600*1600 mm (Can be tailor-made) with high quality copper bus bar
Minco 820B genset module
Minco 810B genset module
Automatic synchronizer SYC6714+
Automatic load sharing module LSM672
DELIXI DW15-100A-3200A Braker
Performance compare of different type of Synchronizing Cabinet
Model |
Operation of parallel using |
Way of load distribution |
Efficiency of parallel using |
Automatic |
Automatic |
Automatic and proportioned |
No fluctuation of frequency |
Semiautomatic |
Automatic |
Automatic and proportioned |
No fluctuation of frequency |
manual |
manual |
Distributed by gen-set |
Frequency fluctutated by load |
Model table of Parallel connection cabinet
type |
model |
current |
Rated efficient power |
Switch capacity |
Automatic |
MB8-300 |
0-630A |
100KW-350KW |
630A |
Automatic |
MB8-400 |
0-800A |
350KW-450KW |
800A |
Automatic |
MB8-500 |
0-1000A |
450KW-550KW |
1000A |
Automatic |
MB8-600 |
0-1250A |
550KW-650KW |
1250A |
Automatic |
MB8-800 |
0-1600A |
650KW-880KW |
1600A |
Automatic |
MB8-1000 |
0-2000A |
880KW-1120KW |
2000A |
Automatic |
MB8-1200 |
0-2500A |
1120KW-1250KW |
2500A |
