Help CenterPreformed Grip / FITTING RETENTION FIBER
Related Products
-
Electric Power Line Fitting Anchor Bracket / Pole Line Bracket With ScrewUS$ 0.08 - 0.38MOQ: 500 Pieces -
Hot Dip Galvanized Mild Steel Shelf Bracket Wall Hook Plate / Iron Anchor BracketUS$ 0.08 - 0.38MOQ: 500 Pieces
-
DT Pure Copper Connecting Terminal Lugs / Factory Direct PriceUS$ 0.1 - 8MOQ: 1000 Pieces
-
DL-10/DL-630 Pin Terminal Alumnium Lug / High Voltage AC Crimp Terminal Connector Ring Wire ConnectorUS$ 0.1 - 5MOQ: 1000 Pieces
-
CU-AL Power Lug Terminal / Bimetallic Compression Lug Connecting TerminalUS$ 0.1 - 6.5MOQ: 1000 Pieces
Application:
OPGW preformed suspension clamp is mainly used to support the suspend OPGW cable. It is suitable for the OPGW cable, conductor and grounding wire on transmission line. It is recommended used on the line with turning angle less than 30 degree.
Features:
1.Reasonable distribution of static stress, good endurance capacity for dynamic stress (such as vibration and waving). The grip strength to cable can reach 10%~20% of cable's ultimate tension strength.
2. No rigidity contact with cable(conductor), minimum abrasion.
3. Excellent materials make the clamp has good elasticity, well tenacity, strong fatigue resistance, well corrosion resistance and long & safe service life.
4. Not only protecting cable, its round and smooth outer shape can reduce the corona discharge and electromagnetic loss immensely.
Composition: Inner reinforcing rod, outer rod, rubber insert, suspension housing, grounding wire, etc.
Material of inner reinforcing rods and outer rods: Aluminum alloy wires.
Customers can also choose other linking fittings such as clevis, Eye chain, etc.
Partial model parameters
Model No. |
L2(mm) |
L1(mm) |
Grip Strength (KN) |
Breaking Strength (KN) |
Span (m) |
Color Code |
Estimate Weight (kg) |
XZTS-OXXXX/007 |
1600 |
1200 |
7 |
≥40 |
200~350 |
Red |
4 |
XZTS-OXXXX/010 |
1900 |
1300 |
10 |
≥55 |
350~450 |
Red |
4.3 |
XZTS-OXXXX/013 |
2000 |
1500 |
13 |
≥70 |
450~600 |
Red |
4.6 |
XZTS-OXXXX/015 |
2300 |
1700 |
15 |
600~800 |
Red |
5 |
|
XZTS-OXXXX/018 |
2600 |
1900 |
18 |
800~1000 |
Red |
6.0 |
