Oral Liquid Honey Syrup Tomato Paste Liquid Sachet
Filling Machine
Features:
1. Advanced performance, high power, low noise, compact structure, Operate steadily , easy to
maintain, and has a long life span.
2. Adopt five shaft servo motor in step driver, man-machine interface touch adjustment,controlled
by PLC, it is precise in automatic in step positioning.
3. A high degree of automatic.Machine can finish packing at one time from longitudinal sealing,
longitudinal cutting, transverse sealing, filling, embossing,notch cutting, cutting Dotted line, transverse
cuttingto outputting finished sachets.
4. High precision whole rolling type heat sealing roller are adopted as sealing mould. 4-side sealing, multi-line sachets form. Because liquid material will easily leak in sealing side, an extra smooth
unstriated sealingroller is setup to ensure sealing sides compact and tightly. With high packing speed,
smooth bag shape, delicate and beautiful, packaging with high efficiency.
5. Fast and convenient to adjust, it can step-less adjust pouch length without changing the mould.And can adjust the functions as longitudinal sealing, transverse sealing, filling, embossing,
Dotted line cutting and transverse cutting through man-machine interface.
6. Accurate in measurement, According to liquid material, specifically designed of centrifugal liquid pump
for filling, measuring control adopt high precise electro-magnetic valve, each valve match with voltage regulator, each line's dosage can be adjusted easily and accurately.
7. A PLC is used for automatic control, Each actuating mechanism adopt servo motor to driver, it is
precise in automatic in step positioning, reliable performance, convenient to operate, and fully automatic.
8. Photoelectric tracking system is adopted to ensure correct printing and with automatic counting function.
9. Adaptability of the package film. the sealing temperature of machine is with automatic control, and
with high control accuracy (± 1C °). Suitable for most complex film packing film in home and abroad,
as PET/AL/PE,PET/PE,NY/AL/PE,NY/PE and so on.
10. Extra function set up, for example, sachet cutting can can choose dotted line knife, flat cutting knife
or abnormal shape knife. And can choose different kinds of alarm requirements and so on.
Main technological parameter:
four-side seal |
|
Bag length: |
50-300mm (adjustable)
|
Bag width: |
35-105mm |
Packing dosage: |
5-100ml |
Packaging speed: |
30-60times/min (depend on pouch size and material) |
Applicable film: |
PET/AL/PE, PET/PE, NY/PE, NY/AL/PE |
Max film width: |
900mm |
Mac film diameter: |
Φ300mm |
Film core diameter: |
Φ75mm |
Power voltage: |
380V/ 50HZ |
Total power: |
12KW |
G.W. |
1500Kg |
Package size: |
1650*1500*2200mm(L*W*H) |
Suitable for packing liquid material in the pharmacy(medicine), food, daily chemical and other industries,
automatic packing into sachet with Measurement requirement, such as ice lolly, soy sauce, vinegar, wine,
medicine (water), chemical agent (water) and much more.
1. Any questions in technical can contact us by e-mail and deal with it.
2. Spare parts replacement and repair service.
3. Engineer can be distributed into overseas required.
Wenzhou Jienuo Machinery & Technology Co., Ltd. is a manufacturing and trading company
which is mainly engaged in development, production and related services for pharmaceutical
industry, food industry, cosmetics industry, stationery industry, etc.
We have been the manufacturer of packing machines for 10 years. If you are interested in our automatic
packing machines, please contact me without hesitation. we will give you the best price.
Company: Wenzhou Wenzhou Jienuo Machinery & Technology Co. Ltd
Tel : 0577-66856266
Mobile/Whatsapp:86-18305876992
Fax: 0577-66856268
QQ: 2592339509
Skype:linyawei16
Q1.What's payment terms ,trade terms you accept ?
Usually we appreciate T/T 30% deposit , then 70% balance is paid before shipment , we usually offer fob ningbo price .but we also accept other way like L/C, wetern union ,and do CFR&CIF
etc.
Q2.Does it easy to operate and what can i do if it doesn't work?
First ,our machine is stable and easy to operate by one man ,what you do is just learn some basic thinglike how to operate PLC .And we will sent you manual and video ,we suggest
you to come to visit our factory to learn more thing by yourself , and if there is something goes
wrong, you can call us ,video-chat ,email us .And we will give solutions within 36 hrs .
Our engineer also can be distributed to overseas as you required.
We provide you with sincerely service, if you have interest,contact us NOW!!!
