High quality custom tungsten carbide nozzle, Top quality tungsten carbide nozzle
- 30 Ton / Tons per Month
- Qingdao Port
- T/T Credit Card
You May Like
-
Tungsten Carbide Nozzle For Oil Drilling in High Quality
-
2016 High quality replace shot blasting nozzle tungsten carbide
-
Tungsten Carbide,Cemented Carbide,Carbide Blanks
-
Tungsten Carbide Inner Rounding Shaft Sleeve YG8 Tungsten Carbide Bush
-
China professional cemented tungsten carbide nozzle
-
best price tungsten carbide spray nozzle for sandblasting
Product Details
| Place of Origin | Shandong, China | Brand Name | Xinyu | |
| Model Number | Tungsten Carbide Nozzle | Alloy Specification | YG6/YG8/YG11/YG13/YG15 | |
| Particle | 1-5 |
Product Description
High quality custom tungsten carbide nozzle, Top quality tungsten carbide nozzle
Grade of Oil Drilling PDC Drill Bits Tungsten Carbide Nozzle
Grades | Density (g/cm³) | Hardness (HRA) | T·R·S (N/mm2) | Application |
YG4C | 15.00 | 89.5 | 1800 | Maily used as small buttons for percussion bits and as the inserts of rotary prospecting bits to cut soft, medium-hard formations. |
YG6 | 14.80 | 89.5 | 1700 | Maily used as the buttons of small and medium-sized percussion bits and as the inserts of rotary prospecting bits to cut soft, medium-hard formations. |
YG8 | 14.70 | 88.5 | 2300 | Maily used as the buttons of small and medium-sized percussion bits and as the inserts of rotary prospecting bits to cut soft, medium-hard formations. |
YG8C | 14.70 | 88.0 | 2300 | Maily used as the buttons of small and medium-sized percussion bits and as the inserts of rotary prospecting bits to cut soft, medium-hard formations. |
YG9C | 14.50 | 87.0 | 2400 | Maily used as the inserts and buttons for rotary-percussive bits, coal-cutting bits and tricone bits to cut medium-hard and hard formations. |
YG11C | 14.40 | 86.5 | 2450 | Chiefly for the inserts and buttons of heavy rock drill bits and rotary-percussive bits, coal-cutting bits and tricone bits to cut medium-hard and hard formations. |
YG13C | 14.30 | 86.0 | 2500 | Mainly used as the inserts and buttons of tricone bits rotary-percussive bits and heavy rock drill bits to cut medium-hard and hard formations. |
YG15 | 14.00 | 86.5 | 2500 | It is stronger, and is mainly used as the inserts and buttons of rotary-percussive bits, heavy rock drill bits to cut hard and very hard formations. |
YG16 | 14.10-14.30 | 87.5 | 2400 | It is mainly used for making cemented carbide substrate tips to be used in PDC cutters for excavating coal and oil field PDC bits. |
YG20 | 13.40-13.70 | 85.0 | 2254 | Mainly for the stamping dies used in the conditions of heavy impact load and large strees. |
Dimension of Oil Drilling PDC Drill Bits Tungsten Carbide Nozzle
TYPE | Dimension mm | ||
ΦD | ΦD1 | h | |
09 | 7.1 | 15.9 | 6.4 |
10 | 7.9 | 15.9 | 7.1 |
11 | 8.7 | 15.9 | 7.7 |
12 | 9.5 | 15.9 | 8.4 |
13 | 10.3 | 15.9 | 9.1 |
14 | 11.1 | 15.9 | 10.0 |
15 | 11.9 | 15.9 | 10.9 |
16 | 12.7 | 15.9 | 11.9 |
17 | 13.5 | 15.9 | 13.2 |
18 | 14.3 | 15.9 | 14.4 |
19 | 15.1 | 15.9 | 15.6 |
20 | 15.9 |
| -- |
22 | 17.4 |
| -- |
We can also produce according to your drawing and requirement.
Advantage of Oil Drilling PDC Drill Bits Tungsten Carbide Nozzle
1. Free sample
2. Direct factory produce and sale
3. Different grades are available
4. Custom-made available
5. Precision processing and strict product inspection
6. Advanced Equipments and Professional technicians
7. Gurantee the bulk quality are in accordance with the samples
8. ISO 9001-2008 Quality Control System
9. 100% virgin tungsten carbide powder
10. High speed cutting,wears well & long service life
11. High hardness, high strength, wear resistance
12. 13 years professional experience
Company Introduction
Founded in 2002, Jinan Xinyu Cemented Carbide Co., Ltd. is a large licenced import and export enterprise integrating R&D, manufacture and trade of cemented carbide in a whole and has strong R&D ability and advanced production facilities. Our products are exported to more than 50 countries and regions across the world including the United States, Canada, Italy, Japan, Korea,Taiwan etc. The cemented carbide and related products of our company is of excellent performance and quality and sold well both at home and abroad. Our company has passed the ISO9001 surveillance and assessment and been praised as the first class AAA credit company.
Certification
Our factory had got the certificate of ISO9001-2008, SGS, BV etc.
Q1 : Are you Factory or trading company ?
We are Factory with 25 years of production experience.
Q2: Where is your factory located ?
We are located in Jinan city, Shandong province where is 2 hour away from Beijing by train.
Q3: Is the price Competitive?
We have our own Factory. Thanks to strong production and distribution system, we
promise to offer our customers the most competitive price.
Q4: Are the products High Quality?
Yes. All products will be tested before bulk production, and we will check the physical properties, shape and tolerance for ensuring qualified products before shipping.
Q5: How to place an order of YG8 carbide,YG8 tungsten carbide,tungsten carbide gripper inserts for chuck jaws ?
1. Fill your Order List in our online Inquiry System.
(Also you can directly contact our salesperson by Email / Skype / Whats App)
2. We will make a feedback to you ASAP after receive your order list.
Q6: How we can trust your company ?
We support Aliababa trade insurance , 100% products quality protection, 100% on time shipment protection, 100% payment protection for your covered amount.
Q7: What’s your delivery time ?
For the normal type which we have mold it takes 7-15 days after receiving the advance payment.
For the non standard which we do not have mold it takes 15- 35 days after receiving the advance payment.
