Aluminium Composite Panel (exterior Panel)

Specifications

Aluminium Composite Panel (Exterior panel ) Specifications:

1. LIKEAIR aluminium composite panel consists of a polyethylene core and two aluminium skins. The panel is produced with various core thickness in a continuous process.

2. Standard: according to GB/T 17748-1999 standard

3. Material:
a) Front: aluminum alloy sheet coated with fluoro-carbon resin (PVDF)

b) Core: nontoxic polyethylene
c) Back: aluminum alloy sheet coated with polyester resin painting
d) Surface finish: exterior facecoil coated with flurocarbon paint;

interior facecoil coated with service paint or mill finish aluminium.
e) Aluminum alloy sheet thickness: 0.2mm, 0.3mm, 0.4mm,0.45mm, 0.5mm (Cover sheet grade: mill finish alloy 3003 H18 .)

4. Dimensions:
a) Panel Thickness: 3mm, 4mm, 5mm and 6mm are available on request
b) Panel Width:1000mm 1220mm 1250mm 1500mm 1570mm etc
c) Panel Length: 2440mm, 2500mm, 3200mm, 4000mm,5000mm (max: 6 meter)
d) Standard size: 1220 x 2440mm
f) Non-standard sizes and special colors are available, according to customers' requests

5.Features

1) Weather resistance, acid resistance, alkali resistance and UV resistance
2) Fireproof (available)
3) Even coating
4) Easy maintenance
5) Excellent torsion strength

6) Abrasion resistance

6. Application scope:

1) Building exterior curtain walls

2) Decoration and renovation additions for old buildings

3) Decoration of interior walls, ceilings, bathrooms, kitchens and balconies

4) Shop door decorations

5) Advertisement board display platforms and signboards

6) Wallboards and ceilings for tunnels

7) Industrial materials, materials for vehicles and boats
