1KW to 5KW On Grid Solar Inverter for Home System

Input (DC)

Max. DC power [W]

1700

2300

3000

3480

4580

4000

5200

Max. DC voltage [V]

550

550

550

550

550

550

550

Max. input current [A]

9

11

13.5

17.5

22

22

26

Number of MPP trackers / Strings per MPP tracker

1 / 1

1 / 1

1 / 1

1 / 2

1 / 2

1 / 2

1 / 2

MPPT voltage range

(at rated power)  [V]

180~500

200~500

210~500

200~500

200~500

200~500

200~500

Shutdown voltage / Start voltage [V]

70 / 100

70 / 100

70 / 100

70 / 100

70 / 100

70 / 100

70 / 100

Output (AC)

AC nominal  power [W]

1500

2000

2600

3000

4000

3680

4600

Max. AC power [W]

1650

2200

2800

3300

4400

3680

5000

Max. AC current [A]

8.6

11

13.8

16

22

16

24

Nominal AC voltage / range [V]

230 / 180~270*

230 / 180~270*

230 / 180~270*

230 / 180~270*

230 / 180~270*

230 / 180~270*

230 / 180~270*

AC grid frequency / range [Hz]

50 / 47~52*

50 / 47~52*

50 / 47~52*

50 / 47~52*

50 / 47~52*

50 / 47~52*

50 / 47~52*

Power factor (cosφ)

1

1

1

1

1

1

1

Total harmonic distortion (THDi) (at nominal power)

<3%

<3%

<3%

<3%

<3%

<3%

<3%

Efficiency

Max. efficiency

96.8%

96.8%

97.0%

97.4%

97.6%

97.6%

97.6%

Euro efficiency

95.8%

96.2%

96.3%

96.5%

97.1%

97.1%

96.8%

MPPT efficiency

99.9%

99.9%

99.9%

99.9%

99.9%

99.9%

99.9%
