Fiberglass Braid Silicone Rubber Coated Cable Sleeve
- 100000 Meter / Meters per Month
- shanghai
- Credit Card
- Wenzhou Yika 7.2KV High Voltage Fuse 63 Amp
- 3240 Epoxy Board, High-quality Insulation Material, Flexible Customization, Widely Applicable 3240 Epoxy Sheet
- Chinese Factory Electrical Insulation Brown 3025 Phenolic Bakelite Resin Cotton Cloth Fabric Laminate Board Sheet Phenolic Board
- 4x8 fiberglass sheets g10 epoxy glass fiber board g10 material
- Factory Price Bakelite Decorative HPL Press plates bakelite sheet
- Black G10 Sheet - High Quality Carbon Fiber G10 FR4 Sheets - Precision-made PCB Materials
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | WYE | Model Number: | Cable Sleeve |
Type: | Insulation Sleeving | Material: | Fiberglass | Application: | Other, High Temperature, High Temperature Environment |
Rated Voltage: | 300V, 600V | Tensile Strength: | >25MPA |
Product Description
Fiberglass Braid Silicone Rubber Coated Cable Sleeve
Composition:
1.Insulator:Fiberglass Braid Sleeve
2.Outer Varnish:Silicone Coating
Packing
-Rolls
Applications
-Wiring for usage in thermal place.
-household appliance.
-Illuminative lamps.
-Industrial lmps.
Caharacteristics
Braided fiberglass sleeving with a uniform coating of silicone rubber. Cuts cleanly and will not fray.
The tubing remains flexible from -60°C to +200°C.
Can be "pushed-back" easily; has high cut through resistance, and is unaffected by corona, ozone,
radiation, weathering and fungus, with excellent abrasion, chemical and moisture resistance, self-extinguishes flame.
Electrical
-Working voltage:300V
-Test voltage:1500/2500/4000/7000V
UL1441
Item | Value |
Continuous operation temperature | -60°c + 200°c |
Temperature Endurance | 200°c ± 2°c 168HRS ≥ 1/2 former voltage value |
Aging Test | 260°c, 6 hours, no cracking |
Extinguish self time | 10s |
Cold Bend | No crack |
Horizontal Flame Test | <30 seconds |
Flame Retardance | VW-1 |
Volume Resistivity | 10^11 ohmscm |
Submerge water test | No gum, not distorion and emollated |
Inner Diameter | Insulation Thickness | |||
mm | 1000V | 1200V | 1500V | 2500V |
1.0 | 0.18 | 0.2 | 0.25 | 0.3 |
1.5 | 0.18 | 0.2 | 0.25 | 0.3 |
2.0 | 0.18 | 0.2 | 0.25 | 0.3 |
2.5 | 0.18 | 0.2 | 0.25 | 0.3 |
3.0 | 0.23 | 0.25 | 0.3 | 0.35 |
4.0 | 0.23 | 0.25 | 0.3 | 0.35 |
5.0 | 0.28 | 0.3 | 0.35 | 0.4 |
6.0 | 0.28 | 0.3 | 0.35 | 0.4 |
7.0 | 0.32 | 0.35 | 0.4 | 0.45 |
8.0 | 0.32 | 0.35 | 0.4 | 0.45 |
9.0 | 0.43 | 0.45 | 0.5 | 0.55 |
10.0 | 0.43 | 0.45 | 0.5 | 0.55 |
11.0 | 0.43 | 0.45 | 0.5 | 0.55 |
12.0 | 0.43 | 0.45 | 0.5 | 0.55 |
14.0 | 0.52 | 0.6 | 0.8 | 0.9 |
16.0 | 0.52 | 0.6 | 0.8 | 0.9 |
18.0 | 0.52 | 0.6 | 0.8 | 0.9 |
20.0 | 0.52 | 0.6 | 0.8 | 0.9 |
Information Included In This Catalog Is Intended As A Guideline Only.
For Applications That Require Tight Tolerances, Please Contact Us For Verification.
