Help CenterPE Heat Shrink Sleeve
US$ 0.05 - 1
MOQ: 5000 Meters
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
CHINAWYE
Model Number:
PE Heat Shrink Sleeve
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Silicone Hose RollUS$ 5.5 - 7.5MOQ: 100 Kilograms -
300V Electrical Fiberglass Wire InsulationUS$ 0.035 - 6.5MOQ: 1000 Meters
-
600V 6mm Fiber Glass Slilcon SleevingUS$ 0.035 - 6.5MOQ: 1000 Meters
-
300V High Temperature Fiberglass Braided SleevingUS$ 0.035 - 6.5MOQ: 1000 Meters
-
Soft Transparent Silicone Rubber TubeUS$ 5.5 - 7.5MOQ: 100 Kilograms
Place of Origin
Jiangsu, China
Brand Name
CHINAWYE
Model Number
PE Heat Shrink Sleeve
Type
Insulation Sleeving
Material
PE
Application
High Temperature
Rated Voltage
600V
Features
Operating Temperature : -45°C~125°C
Shrink Ratio : 2:1
Shrink Temperature : Start at 70°C,and shrunk totally at 110°C or 115°C(CB)
Size Range : ID:0.6-50
Standard : UL224
Available Color : Black/Transparent/Other colors
| Properties | Condition | Value |
| Physical | ≥10.4Mpa | |
| Tensile strength | ≥200% | |
| Longation | ||
| Tensile strength afrer aging | 158±1°C,168hr | ≥70% oforiginal |
| Elongation after aging | 158±1°C ,168hr | ≥100% |
| Heat shock | 250°C ,1hr | No cracking |
| Cold bend | -30°C ,1hr | No cracking |
| Electrical | ||
| DielectricVoltage withstand | 60sec | ≥2500V |
| Volume resistivity | ≥1014Ω·cm | |
| Chemical | ||
| Corrosion | 158±1°C ,168hr | Pass |
| Copper stability | 158±1°C ,168hr | Pass |
| Flammability | VW-1 | VW-1 |
| Voltage rating | 600V/300V | |
| Temperature rating | 125°C |
- Protect Wiring with this Professional Grade Tubing!
- Fast, safe, secure way to wrap wiring harnesses. Protects and insulates.
- Great variety of top pro quality heat shrink tubing. Will shrink up to half of original diameter.
- Heat shrinkable tube has excellent un-flammability, flexibility, and insulation.
- The shrinking temperature is very low and it can shrink very quickly.
