Home > Industrial Equipment & Components > Fastener & Fitting > Combination & Joint Fittings > Plastic Hit Anchor for Solid Brick/Masonry
Plastic Hit Anchor for Solid Brick/Masonry
US$ 0.1 - 1
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Fixingmore
Model Number:
OEM
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Plastic Fastener Nylon Plug Screw Plastic Anchor Nylon Expansion ScrewUS$ 0.1 - 1MOQ: 1000 Pieces -
Nylon Frame Fixing Anchor With Nail ScrewUS$ 0.1 - 1MOQ: 1000 Pieces
-
All Kinds of Nylon Hammer Drive Plastic Wall AnchorUS$ 0.1 - 1MOQ: 1000 Pieces
-
Wing Nylon Nail Anchor/Nylon Hammer Drive Anchor With Nail ScrewUS$ 0.1 - 1MOQ: 1000 Pieces
-
Fishlook Plastic Hammer Drive Anchor/zamac Nail ScrewUS$ 0.1 - 1MOQ: 1000 Pieces
Place of Origin
Zhejiang, China
Brand Name
Fixingmore
Model Number
OEM
Type
Hammer Drive Anchor
Material
Other, Nylon/PE+Carbon Steel/ZP
Diameter
M5- M8 (3/16" to 1/4")
Length
25mm -140mm (1" to 6")
Capacity
0.23-0.32KN. (50-70LBS.)
Standard
Other, DIN, ANSI,ASTM, GB,etc
Nylon Nail Anchor/Nylon Hammer Drive Anchor Nylon With Flange Head
Base Material
Uncracked Concrete
Hollow-core Concrete Slabs
Natural Stone
Solid Brick/Masonry
Light Weight Concrete
Product Advantages
1. ISO9001:2000 Certified ,CE, GS
2. Quality Control inspection Before Shipment
3. Appearance: Bright neat body, without any burrs
4. Tolerances: Precision Tolerances to Customer Specification
5. Non-standard/ OEM/ODM/customized service provided
Specifications Model
A. METRIC
| CODE | SIZE | DRILL DIA. | MIN. EMBEDMENT DEP. | TENSION(KN.)** |
| NNA05025 | M5X25 | 5mm | 20mm | 0.23 |
| NNA05030 | M5X30 | 5mm | ||
| NNA05035 | M5X35 | 5mm | ||
| NNA05040 | M5X40 | 5mm | 25mm | 0.25 |
| NNA05045 | M5X45 | 5mm | ||
| NNA05050 | M5X50 | 5mm | ||
| NNA06035 | X6X35 | 6mm | 15mm | 0.16 |
| NNA06040 | M6X40 | 6mm | ||
| NNA06050 | M6X50 | 6mm | 20mm | 0.27 |
| NNA06060 | M6X60 | 6mm | ||
| NNA06070 | M6X70 | 6mm | 25mm | 0.30 |
| NNA06080 | M6X80 | 6mm | ||
| NNA08050 | M8X50 | 8mm | 40mm | 0.32 |
| NNA08060 | M8X60 | 8mm | ||
| NNA08080 | M8X80 | 8mm | ||
| NNA08100 | M8X100 | 8mm | 50mm | 0.32 |
| NNA08120 | M8X120 | 8mm | ||
| NNA08140 | M8X140 | 8mm |
B.INCH
| CODE | DRILL DIA. | MIN. EMBEDMENT DEP. | TENSION(LBS.)** |
| NNA3161 | 3/16" | 3/4" | 50 |
| 1" | 55 | ||
| NNA1434 | 1/4" | 5/8" | 35 |
| NNA141 | 3/4" | 60 | |
| NNA14112 | |||
| NNA142 | 1" | ||
| NNA143 | |||
| NNA144 | 1-1/2" | 70 | |
| NNA146 | 2" | 70 |
** Tabulated load values are for anchors installed in concrete(Concrete C20/25).
Concrete compressive strength must be at the specified minimum at the time of installation.
