Nylon Speed Drive Anchor / Plastic drive anchor
Product Description
The plastic drywall anchor is a one piece self drilling anchor designed for use in hollow gypsum wallboard for light duty loads.
It is available in both engineered nylon and Zamac alloy for use with either a No.6 or No.8 screws in 3/8” to 1” wallboard.
The plastic drywall anchor is formed from engineered nylon for use with No.6 screws in 3/8” to 5/8” wallboard.
Base Material
Wallboard
Product Advantages
1. ISO9001:2000 Certified ,CE, GS
2. Quality Control inspection Before Shipment
3. Appearance: Bright neat body, without any burrs
4. Tolerances: Precision Tolerances to Customer Specification
5. Non-standard/ OEM/ODM/customized service provided
Specifications Model
A. METRIC
| CODE | SIZE | DRILL DIA. | PLUG LEN. | SCREW DIA. |
| PDA1035 | 10*35 | 10 | 35mm | 3.5-4.0 |
| PDA1340 | 13*40 | 13 | 40mm | 4.0-5.5 |
| PDA1342 | 13*42 | 13 | 42mm | 4.0-5.5 |
| PDA1423 | 14*23 | 14 | 23mm | 4.0-5.5 |
| PDA1428 | 14*28 | 14 | 28mm | 4.0-5.5 |
| PDA1432 | 14*32 | 14 | 32mm | 4.0-5.5 |
B. INCH
| CODE | WALL THICKNESS | DESCRIPTION |
| PDA0001 | 3/8" to 1" | Std. box, no screws |
| PDA0002 | 3/8" to 1" | Std. box,No.8x1" screws |
| PDA0003 | 3/8" to 1" | Master ctn, no screws |
** Tabulated load values are for anchors installed in concrete(Concrete C20/25).
Concrete compressive strength must be at the specified minimum at the time of installation.
