Good Used in Kenya Uganda Chalk Moulding Machine
Chalk Moulding Machine Features:
1.Raw material is mixed by manually for FC400-1 and FC800-1
2.Raw material is mixed by electric mixer machine for FC800-2,FC800-4,FC800-6,FC800-8.
3. the raw material is plsater of Paris or gypsum powder, simple operation and low cost.
4.size and color of chalk are adjustable.
5.row material:mold for steel,mold tube for ABS material
Chalk Moulding Machine parameters for your reference:
Model No. |
Capacity (pcs/h) |
Packing size (mm) |
Chalk Big head |
Chalk Small head |
Chalk Length |
Machine Weight |
FC400-1 |
2000-4000 |
530*380*340 |
10mm |
8mm |
75mm |
30kg |
FC800-1 |
4000-8000 |
660*480*360 |
10mm |
8mm |
75mm |
65kg |
FC800-2 |
8000-12000 |
1800×1150×800 |
10mm |
8mm |
75mm |
260kg |
FC800-4 |
12000-24000 |
1800×1150×800 |
10mm |
8mm |
75mm |
350kg |
FC800-6 |
24000-32000 |
1800×1150×800 |
10mm |
8mm |
75mm |
600kg |
FC800-8 |
32000-48000 |
1800×1150×800 |
10mm |
8mm |
75mm |
860kg |
Chalk Moulding Machine pictures:
Advantages of Chalk Moulding Machine
1,dustless chalk machine
2,low labor intensity
3,no material-wasting
4,delicate appearance
5,high effective
6,best quality
Operating process of Chalk Moulding Machine
1.Brushing oil.When you start to use this chalk machine, move the chalk mold upward,and then brush oil on the mold,new mold need to brush more oil,and note brushing oil uniformly is very important!
2.Move the mandrel up and down for several times,and then put it in the bottom,four top screws contact prevail.
3.Mixing chalk pulp.the raw pulp needs to be mixed uniformly.
4.Filling chalk pulp.and then poured into the mold, with a scraper to strike off.
5.Molding.Normally it will cost 2-8 minutes for forming and molding,and then you can press chalks by hand.
6.Taking out.Turn the mold 180 °over, then take them out.
FAQ of School Chalk Making Machine
1.Q:What is the type of your chalk machine?
A:FC400-1 and FC800-1 is the manual type,and the others are with electric mixer.
2.Q:What kind of chalks can this make?
A:This machine can make white and color chalks,and dustless chalks which according to your raw materials.
3.Q:How long does the chalks can be made per time?
A:Normally it will cost 2-8 mins per time.
