Specifications
Coal-fired hot air heater
1.Stainless steel heat exchanger
2.Two wind outlet design
3.Maintenance and cleaning is convenient
Technical parameters
| Basic parameters | Unit | JML-5D | JML-10D | JML-20D | JML-30D |
| Rated heat | 10 000 kcal | 5 | 10 | 20 | 30 |
| Thermal efficiency | % | ≥90 | ≥90 | ≥90 | ≥90 |
| Hot air outlet temperature | °C | 60-80 | 60-80 | 60-80 | 60-80 |
| Rated amount of hot air | m3/h | 708-2368 | 1688-6517 | 4012-7419 | 3376-13034 |
| Rated coal consumption | kg/h | 10-20 | 20-30 | 25-35 | 35-50 |
| For fuel | Semi-anthracite | Semi-anthracite | Semi-anthracite | Semi-anthracite | |
| Dimensions | mm | 1680*950*1950 | 2230*1050*2280 | 2350*1180*2520 | 2380*1180*2520 |
| Weight | kg | 500 | 1100 | 1800 | 1980 |
| Voltage | V | 220/380 | 220/380 | 220/380 | 220/380 |
| Power | W | 1620 | 3750 | 5150 | 6750 |
| Heating area | m2 | >300 | >600 | >1200 | >1500 |
Features
1. Aonuodi greenhouse coal fired hot air generator features high thermal efficiency (>=90%) and wide heating area(max. 1500 m2).
2. It adopts a newly designed high-efficiency stainless steel heat exchanger.
3. Heightened combustion chamber is made of 321(1Cr18Ni9Ti) stainless steel, resulting in an extended service life.
4. The dust catcher can effectively remove the dust.
5. Special air outlet design, customization available.
6. The unique heat insulation design helps keep heat loss to a minimum.
7. The coal fired hot air generator is compliant with applicable environmental standards, so customers can feel secure in their purchase.
