HXC-233G quilting embroidery machine,bedspread,garment making machine

Specifications

1.pansonnic servo motor.
2.bedspread garment making machine
3.CE,ISO9001:2000
puterized quilting embroidery machine.



Haimen Haoxin Machinery Co.,Ltd

Add:Desheng Town,Haimen City,Jiangsu,China



Technical Specification
Model	Working width (mm)	Machine dimensions (m)L*W*H	space between two needle head (mm)	Needle quantity	Quilting thickness (g/m2)	Weight (t)	Power (kw)
HXC225G	3352	5.3*1.3*2	67.5	50	50-300	3.5	5
HXC233G	3375	5.3*1.3*2	50.8	66	50-300	3.5	5



Configuration

1.Main shaft motor:Panasonnic servo motor

2.power:3-phase 380V 50HZ

puter system:Daohao yida

4.Speed of rotation shuttle:500-850rpm

5.Stitch length:in binary way :0.15-12.7mm

6.Power consumption:4.5-5.5kw

7.Rotary hook:big rotary hook



Performance

1.Quilting and embroidery completed simultaneouslt.

2.Driving by roller system.

3.Keep plain by tension motor for imparted fabric .

4.Keep embroidery precision by servodriving at x/y axis.

5.Auto-return for patch-up embroidery function.

6.Freely heads quilting function.

7.Cotinuously quilting independent patterns function.

8.Taijima,Barudan,ZSK,and SWF formats are readable.

9.Unique mechanical structure can diminish self-vibration and noises.

10.Professional to produce bed cover,garment,sleeping forter and other textile product.

11.Various stuffs are available for embroidery.
