250w cigs flexible thin film solar module with htgh efficiency thin film solar cell
ELECTRICAL PERFORMANCE | |
Pmax | 250W |
Tolerance of Pmax | ± 7% |
Module aperture area efficiency | 10.50% |
Rated voltage | 48.6V |
Rated current | 5.1A |
Open circuit voltage | 65.4V |
Short circuit current | 6.2A |
Note 1: Standard Test Conditions (STC): Cell Temperature at 25°C; Solar irradiance intensity of 1000 W/m2; AM1.5 solar reference spectrum (ASTM E892) | |
MECHANICAL SPECIFICATIONS | |
Length | 5745mm |
Width | 492mm |
Thickness | 3mm |
Weight(without adhesive) | 7.2kg, (2.7kg/m2) |
Weight(with adhesive) | 9.5kg, (3.5kg/m2) |
Junction Box - Top Mounted | TE Connectivity SOLARLOKTM Micro Junction Box (Optional) |
cables | 4 mm2 dual rated with SOLARLOKTM connectors |
Junction Box - Bottom Mounted | MC-JM/FM (MC4 Connectors) (Optional) |
Front Sheet | Non-stick ETFE |
Solar Cells | 108pieces cell |
Adhesive | Butyl rubber |
Hot Spot Protection | Bypass diodes at each cell; 1 at junction box |
Materials | Lead free and exempt from RoHS requirements |
Maximum Series Fuse Rating | 10A |
Color Options | Black (B) or White (W) backsheet behind cells |
TEMPERATURE COEFFICIENTS | Low-Light Performance |
| |
Maximum power(Pmax) | (-0.43%/℃) | 1000W/m2 | 100% |
Maximum voltage(Vmax) | (-0.38%/℃) | 500W/m2 | 99% |
Open circuit voltage(Voc) | (-0.33%/℃) | 200W/m2 | 91% |
Short circuit current(Isc) | (-0.03%/℃) |
|
|
Note: Relative to Standard Test Conditions (STC): Solar irradiance intensity of 1000 W/m2; AM1.5 | Note: Relative to Standard Test Conditions(STC): Cell Temperature at 25°C; AM1.5 | ||
solar reference spectrum (ASTM E892) | solar reference spectrum (ASTM E892) | ||
QUALIFICATIONS AND CERTIFICATES |
match the follow standard:IEC61646 UL1703 EN61730-1 EN61703-2 ICC-ES AC365 |
Materials and workmanship - 5 years;Power output - 25 years (90% @ 10 yrs; 80% @ 25 yrs) Limited Warranty |
1. Reply your inquiry in 12 working hours
2. Customized design is available, OEM is welcomed
Q: How to palce an order after choosing the products?
A: Please contact our customer service representative for details.
Q: Can you accept OEM service?
A: Yes, we can. Qty is not the only standard, more quality, less cost.
Q: How about your after sales-service?
A: 10 years limited warranty on material and workmanship,
12 years warranty on power output to not fall below 90%,
25 years warranty on power output to not fall below 80%.
Q: How about your payment terms?
A: We accept T/T, Western Union, Money Gram, L/C.
Q: What certification do you have?
A: We have CE/IEC/CSA/CQC/CEC or According to your need, if you place an big order.
