50W Wireless microwave TV transmitter
CKUB-T50
Product Introduction
A. Optimized products indicators, meet the requirement of wide frequency band transmission, reduce investment,save energy to decrease operation cost.
C. Compatible with 4 different digital TV standards: ATSC (USA) / DVB-T/T2 (Europe) /ISDB-T (Japan) / DTMB (China)
Main Features
1) Wild-type waterproof design, simple and attractive appearance, suitable for outdoor work.
2) Support all standard digital TV, mobile TV signal transmission and signal complement point, support single spectrum and wide-band (multi-spectral) amplification.
3) Patented RF delay technology. Avoid the interference with multi-point signal cross-coverage.
4) Large range AGC control circuit (50dB), high-precision ALC compensation function, ensure the output power stability when external signal large changes
5) Complete protection functions: self-excitation protection, temperature control protection, signal fast impact protection, power protection, temperature control protection, password security control.
6) Microcomputer control, support remote debugging and monitoring after equipped with communication module (GPRS).
7) Equipment customization: optical input type, microwave input type, single frequency network delay adjustable type.
Specification
TECHNICAL SPECIFICATIONS | |
Frequency Range |
470~862MHZ (arbitrary range within 100MHz) |
Input signal |
RF |
Shoulder |
≤-36 dB(Single channel) |
(MER) |
≥ 32 dB |
Input port impedance/connector |
50Ω/SMA-50K |
Output port impedance/connector |
50Ω/1-5/8 (customization available) |
Power supply |
AC220V±10%, 45Hz-60Hz; AC110V±10%,45Hz-60Hz(optional) AC60V±10%,45Hz-60Hz(optional) |
Cooling system |
temperature-controlled air cooling |
Operating temperature range |
-22℃ ~ 55℃ |
Dimension (L×W×H) |
500×405×230mm/20kg |
Company file
Since established in High-tech Information Industrial Park Guilin, China in 2000, Guilin CEKE Communication Equipment Co., Ltd is dedicated in R&D, manufacturing, sales, engineering, technical support and after-sales service of MMDS transmitters, digital TV transmitters/repeaters as well as TV and radio microwave transmission equipment for radio &TV broadcasting. Our products have been certified by ISO9001 and got more than 10 patents, and have been exported to customers in 40 countries and regions Europe, America, Central Asia, Southeast Asia, Africa and Oceania.
We are not only provider of equipment but also a global provider of integrated solution for pay-TV broadcasting. We have successfully DTTV system integration projects countries like Sri Lanka, Kyrgyzstan, Costa Rica, Madagascar, Vanuatu and Equatorial Guinea.
