Home > Consumer Electronics > Warmer Appliance > Heater Fan > U Shape 1kwatts High Power Industrial Finned Tubular Heater

U Shape 1kwatts High Power Industrial Finned Tubular Heater

Name: U Shape 1kwatts High Power Industrial Finned Tubular Heater
Brand: Topright
SKU: 126422475

U Shape 1kwatts High Power Industrial Finned Tubular Heater thumbnail-1

U Shape 1kwatts High Power Industrial Finned Tubular Heater thumbnail-2

U Shape 1kwatts High Power Industrial Finned Tubular Heater thumbnail-3

U Shape 1kwatts High Power Industrial Finned Tubular Heater thumbnail-4

U Shape 1kwatts High Power Industrial Finned Tubular Heater thumbnail-5

U Shape 1kwatts High Power Industrial Finned Tubular Heater photo-1

U Shape 1kwatts High Power Industrial Finned Tubular Heater photo-2

U Shape 1kwatts High Power Industrial Finned Tubular Heater photo-3

U Shape 1kwatts High Power Industrial Finned Tubular Heater photo-4

U Shape 1kwatts High Power Industrial Finned Tubular Heater photo-5

US$ 2.5 - 15 MOQ: 10 Pieces

Key Specifications

Get Latest Price

Condition:

New

Type:

Air Heater

Power Source:

Electric

Contact Supplier Request Quote Chat Now

Topright Industrial Technology Yancheng Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Air Heater

Power Source Electric

Place of Origin Jiangsu, China

Brand Name Topright

Model Number TRFHT12016080807

Dimension(L*W*H) customized

Weight 0.3

Voltage 220-380V, 220-380v

Power(W) 1-3KW

Certification CE ROHS

Warranty one year

After-sales Service Provided Overseas third-party support available

Specifications

1) NIickel chromium resistance wire
2)Tube material SS304/316/321/Incoloy
3)high efficient heat transfer

Product Description:

Topright Brand finned tubular heaters provide rapid heat transfer for natural convection or forced air

space heating in industrial process air heating systems.

Finned tubular heaters start out as a standard tubular heater with the fins being attached

on a custom built finning machine.

Features:

Mild steel sheath models are suitable for operating temperatures to 500C

Premium grade magnesium oxide insulation imbeds the resistance wire coil for optimum heat transfer

High temperature nickel chromum resistance wire

Full brazed wound fin

Standard and custom options available

*Standard size and material*
Specifications
Standard diameter: 11mm	Standard fin diameter: 23mm
Material: 304SS, 316SS	Terminations: All Tubular Heater
Min. Sheath Length: 500mm	Max. Volts: 480 Vac
Max. Sheath Length: 256"	Max. Amperage: 40 Amp

Specifications 2:

TUBE MATERIAL	FIN MATERIAL	TUBE DIA.(MM)	FIN HEIGHT(MM)	FIN THICKNESS(MM)	FIN PITCH(MM)
SS304/316/321/Incoloy	S.Steel / mild Steel	Φ6.7	3-5	0.3-0.4	3-5
SS304/316/321/Incoloy	S.Steel / mild Steel	Φ8	3-5	0.3-0.4	3-5
SS304/316/321/Incoloy	S.Steel / mild Steel	Φ9	3-5	0.3-0.4	3-5
SS304/316/321/Incoloy	S.Steel / mild Steel	Φ10	5-7	0.3-0.4	3-7
SS304/316/321/Incoloy	S.Steel / mild Steel	Φ12	5-7	0.3-0.4	3-7
SS304/316/321/Incoloy	S.Steel / mild Steel	Φ14	5-10	0.3-0.4	3-7
SS304/316/321/Incoloy	S.Steel / mild Steel	Φ16	5-10	0.3-0.4	5-10
SS304/316/321/Incoloy	S.Steel / mild Steel	Φ20	5-10	0.3-0.4	7-10

Standard constructions:

Finned tubular heater photos:

Typical Applications:

Caustic Cyanide used in gold processing

Hot water storage

Asphalt Wax

Caustic solutions Detergent

Sterilizing equipment

Heating oils

Plastic processing&packaging machinery

Ovens&dryers

Dies&Tools

Water& Oil heating appliances

Vending machines

Kitchen equipments

Medical equipments

Packaging and shipping:

Our service:

1.Inquiry-Professional Quotation

2. Confirm the price, lead time, artwork, payment term etc.

3. Topright sales send the Proforma Invoice with Topright seal.

4. Customer make the payment for deposit and send us Bank receipt.

5. Initial Production Stage-Inform the clients that we have got the payment,And will make the products according to your request,. After getting the sample or drawing approval, we inform that we will arrange the production & inform the estimated time.

6. If possible,middle Production-send photos to show the production line which you can see your products in . Confirm the estimated delivery time again.

7. End Production-Mass production products photos will send to you for approval. You can also arrange the third party Inspection .

8. Clients make payment for balance and Topright Ship the goods .Also can accept payment term-Balance against B/L Copy Or L/C payment Term which we discussed. Inform the tracking number and check the status for clients.
