Help CenterDia.8.5mm Double Ended Tubular Heater
Related Products
-
Coil Type Double Ended Tube Electric Tubular HeaterUS$ 20 - 80MOQ: 5 Pieces -
Coil Double Head Electric Tubular HeaterUS$ 10 - 30MOQ: 10 Pieces
-
220v 9250w 3 Phrase Flange Tubular Heater With 2" Hex FlangeUS$ 10 - 30MOQ: 10 Pieces
-
Hex Flange Electric Immersion Tubular Heater for Electric Water Heater 240v 9250wUS$ 10 - 30MOQ: 10 Pieces
-
SUS304 240v 9250w 1.5" 3 Phrase Tubular Immersion HeaterUS$ 20 - 80MOQ: 5 Pieces
Quick Details:
1) NIickel chromium resistance wire
2)Tube material SS304/316/321/Incoloy
3)high efficient heat transfer
Topright Brand Tubular heating element are used for almost every kind of heating appliances. They are easy to form and feature highest mechanic stability and electric properties at the same time.
Even though Tubular heating element are technically rather mature and universal to use, there exist various new innovative solutions for many applications.
Screw in Tubular heating element are standardised for use in liquids like water.
Tubular heating element are easy to install,control and maintain, unique designer as your requirement. For corrosive enviroment, titanium material or tubular heating elements with additional teflon sleeving are available.
Features:
| HI-POT Test | 1500V/S min cold condition |
| Insulation resistance | 20M Ω min |
| Leakage current | 0.75ma max |
| Power tolerance | +5%,-10% |
| Voltage | 110v-440V |
| Diameter range | 1mm to 40mm |
| Heating resistance wire | 0Cr25Al5,Cr20Ni80 or as custom's requirement |
| Air tubular heater wattage | ≥ 2w-4w/cm2 |
| Water tubular heater wattage | ≥ 6w-10w/cm2 |
| Dies and fin tubular heater | ≥ 8W-12w/cm2 |
Tubular heater photos in Topright Industrial Technology and etc:
Tubular heater structure:
Liquid Immersion
Plastic Molds
Dies
Labeling
Medical Equipment
Platens
Packaging Equipment
Hot Stamping
Sealing
Injection Molding
Tubular Heater Features & Benefits:
Topright Technology Culture:
Since 2001,Topright have been engaged in the development, design, production and sales in one of the sales of industrial technology company, according to the customer needs, provide tailored solution of design, committed to the electric heating and temperature measurement in the field of development. Topright's products have been exported to Europe, America, Asia,Mid East etc. more than 90 countries. We supply different heating element for example silicone rubber heater, kapton heater, band heater, cartridge heater, tubular heater, thermocouple and ect. More details pls link online store:
How does your factory do regarding quality control?
"Quality is in my hand,customer in our heart”. Topright people always attach great importance to quality controlling from the very beginning to the very end.
Topright continuously strive to find ways of reducing our production costs, and passing the savings over to you.Superior quality, stylish designs, competitive price and perfect service won us honorable customers.Topright service includes regular and thorough inspections throughout the manufacturing process, eliminating the need to employ additional quality control inspectors.
Topright run with you together !
