Help CenterDouble Needle Thermocouple With Spring Cable
Related Products
-
Temperature Sensor Assembly Thermocouple With Movable FlangeUS$ 2 - 35MOQ: 10 Pieces -
WRN-230 High Quality Gas Oven Thermocouple for Fireplace,Stove and Water HeatersUS$ 2 - 35MOQ: 10 Pieces
-
High Temp Thermocouple K Type ProbeTemperature Sensors With Terminal HeadUS$ 2 - 30MOQ: 10 Pieces
-
TP 0-1600C 16mm Diameter Thermocouple Type sUS$ 2 - 200MOQ: 2 Pieces
-
K Type Thermocouple Temperature Sensors for Exhaust Gas Temperature (EGT) With 1/8" NPT Adjustable Compression FittingsUS$ 2 - 30MOQ: 10 Pieces
Thermocouple Description:
Thermocouples are very simple and durable temperature sensors. Thermocouple come with different pairings of materials allowing for a very wide range of applications. The different compositions are standardized into thermocouple types. The different types are given letter names which are standardized across the industry.
Thermocouples are manufactured in many different configurations for multitude of applications. Diameters, lengths, sheath material, lead lengths and sensor material are just a few of the variables that go into determining the style of thermocouple when manufactured. The main determining factors of what type thermocouple needs to be used in a application is temperature, environment, response time and accuracy. The junction of the thermocouple can be grounded, ungrounded or exposed.
Thermocouples are easy to use, Thermocouples are the most popular temperature sensors. They are cheap, interchangeable, have standard connectors and can measure a wide range of temperatures.
Thermocouples and RTD pt100 sensors technical indicators:
Product |
Conductor material |
Type |
Graduation |
Use temperature°C (short time) |
Use temperature°C
|
|
|
Thermocouple |
PtRh30-Ptrh6 |
WRR |
B |
0-1800°C |
0-1600°C |
|
PtRh10-Pt |
WRP |
S |
0-1600°C |
0-1300°C |
||
PtRh13-pT |
WRB |
R |
0-1600°C |
0-1300°C |
||
NiCrSi-NiSi |
WRM |
N |
0-1000°C |
0-1000°C |
||
NiCr-NiAl(Si) |
WRN |
K |
0-1200°C |
0-900°C |
||
NrCr-constantan |
WRE |
E |
0-700°C |
0-600°C |
||
Iron- Constantan |
WRF |
J |
0-600°C |
0-500°C |
||
Copper-Constantan |
WRC |
T |
0-400°C |
0-350°C |
||
|
Thermal resistance |
Copper heat resistance |
|
Cu50 |
|
-50-150°C |
|
|
Cu100 |
|
-50-150°C |
|||
|
Pt100 |
|
-200-600°C |
|||
Since 2001,Topright have been engaged in the development, design, production and sales in one of the sales of industrial technology company, according to the customer needs, provide tailored solution of design, committed to the electric heating and temperature measurement in the field of development. Topright's products have been exported to Europe, America, Asia,Mid East etc. more than 200 countries. We supply different heating element for example silicone rubber heater, kapton heater, band heater, cartridge heater, tubular heater, thermocouple and ect. More details pls link online store:
1. Inquiry-Professional quotation. |
2. Confirm the price, lead time, artwork, payment term etc. |
3. Topright sales send the Proforma Invoice with Topright seal. |
4. Customer make the payment for deposit and send us Bank receipt. |
5.Initial Production Stage-Inform the clients that we have got the payment,And will make the products according to your request,. After getting the sample or drawing approval, we inform that we will arrange the production & inform the estimated time. |
6. If possible,middle Production-send photos to show the production line which you can see your products in . Confirm the estimated delivery time again. |
7. End Production-Mass production products photos will send to you for approval. You can also arrange the third party Inspection . |
8. Clients make payment for balance and Topright Ship the goods .Also can accept payment term-Balance against B/L Copy Or L/C payment Term which we discussed. Inform the tracking number and check the status for clients. |
RAQ:
1. Why the price is so low?
You are ordering directly from the factory.
2.Where is your factory located? How can I visit there?
Our factory is located in Yancheng City, Jiangsu Province, China, about 4 hours bus ride from Shanghai .All our clients, from home or abroad, are warmly welcome to visit us.
3.What type of payment do you have available?
A:We accept TT and L/C,as sample order,the Western Union,Money gram and Aliexpress is available.
4.How can I get some samples?
We are honored to offer you samples.
5.How does your factory do regarding quality control?
"Quality is in my hand,customer in our heart”. Topright people always attach great importance to quality controlling from the very beginning to the very end.
Welcome to contact us for more details ,most competitive price for you!
