Help CenterTopright Silicon Nitride Electric Heater 1500w
Related Products
-
Hot Pressed Silicon Nitride Igniter, Electric Silicon Nitride HeaterUS$ 10 - 30MOQ: 5 Pieces -
Silicon Nitride Igniter Heater for Water Heating ElementUS$ 10 - 30MOQ: 5 Pieces
-
187mmx17mmx4mm 2000w Silicon Nitride Igniter HeaterUS$ 8 - 25MOQ: 10 Pieces
-
Silicon Nitride Igniter and Silicon Nitride Heater, Silicon Nitride Heating ElementUS$ 10 - 30MOQ: 5 Pieces
-
High Temperature Instantly Lit Silicon Nitride Heaters for Water Heating ElementUS$ 10 - 30MOQ: 5 Pieces
Topright supply Silicon Nitride ceramic heater-Small Dimension
Topright supply Silicon Nitride ceramic heater-Fast Heating
Topright supply Silicon Nitride ceramic heater-Good Corrosion
Topright supply Silicon Nitride ceramic heater-Long Working life
Topright silicon nitride glow igniters are normally rectangular in shape. These igniters have a hot
operation zone up to 1000 C and a cold zone in the contact area. Encapsulated terminal can
prevent short circuit caused by conductive contamination. They can be operated with or
without a controller. Silicon nitride igniters have several times the durability than that of silicon
carbide products.Dimension, power and input voltage are customizable according to your need.
Type &Parameters:
| Model | Dimension | Paramete | ||||||||
| L | LH | WH | LA | WA | DA | DH | Voltage(V) | Wattage(W) | Max.Temp.(C) | |
| TH138 | 138 | 94 | 17 | 23 | 25 | 12 | 4 | AC220-240 | 700/450 | 1000/800 |
| TH128 | 128 | 84 | 17 | 23 | 25 | 12 | 4 | AC220-240 | 600/400 | 1000/800 |
| TH95 | 95 | 58 | 17 | 23 | 25 | 12 | 4 | AC220-240 | 400 | 1000 |
| TH52 | 52 | 15 | 17 | 23 | 25 | 12 | 4 | AC110 | 100 | 1000 |
| TH135 | 135 | 98 | 23 | 23 | 31 | 12 | 4 | AC220-240 | 900/600 | 1000/800 |
| TH115 | 115 | 76 | 30 | 25 | 38 | 12 | 4 | AC220-240 | 900/600 | 1000/800 |
Topright Brands Silicone Nitride Glow Igniter Photos:
Application:
1.Ignition of solid fuels (e.g. wood pellets)
2.Ignition of gas or oil
3.Reburning or igniter of exhaust fumes
4.heating of process gases
5.Pyrotechnics
6.Brazing machines
7. Heater for corrosive atmosphere
8.R&D - laboratory equipment, measuring and testing
equipment, reactors
9.Tool heating
10. Charcoal barbecue grill
Since 2001, Topright Industrial Technology is engaged in the development, design, production and sales in one of the sales of industrial electric heating technology company, according to the customer needs, provide tailored solution of design, committed to the electric heating and temperature measurement in the field of development more than 15 years, constantly pursuit of technological value-added products,promote industry technology progress, Topright products have been exported to Europe, the americas, Asia, etc. More than 200 countries.
