Lovely animal shape electric sightseeing bus made in china

Name: Lovely animal shape electric sightseeing bus made in china
Brand: HONGDU
Price: Negotiable

FOB Price

Negotiable / Set

1 Set(Min.Order)

Product Details

Place of Origin:

Jiangsu, China

Brand Name:

HONGDU

Model Number:

YMJ-619

19 passengers electric sightseeing bus
optional color without extra cost
lovely shape
an attractive view in resorts

Green power 19 seats tourist bus 6.3kw

Item	Description
Technical parameter	Overall dimensions	6300mm×1620mm×2200mm
	Unloading weight	1800kg
	Min. ground clearance	150mm
	Max. speed(loaded)	25km/h
	Max. distance range	80km
	Max. climbing ability(loaded)	25%
	Min. turning radius	≤5.5m
	Passenger capacity	19
Electric system	Battery	double 48V/220AH
	Charger	input 110V-240V~50Hz-60Hz, output 48V, 25A
	Controller	curtis
	Motor	6.3KW DC series excitation
	Lighting system and horn	2 combined front lights(headlight, turning light, position light), 2 front fog lights, 2 taillight(turn signals and brake lights), horn, rear buzzer
	Dashboard meter	voltammeter, ammeter, odometer, emergency switch; combined switch, meter indicator
	Audio System	radio and MP3 adaptor, with 2 speakers
	Wiper	single arm
Steering and suspension	Transmission system	rear engine Rear wheel drive(RR)
	Steering system	gear rack type steering machine, automatic clearance compensation function
	Front axle and suspension	integral front drive axle, leaf spring independent suspension
	Rear axle and suspension	integral type rear axle, leaf spring independent suspension
	Braking system	four wheel hydraulic drum brake+ parking brake
	Wheel & tyre	steel rim, tubeless tyre 600-14
Body and frame	Frame	high quality carbon pipe welding rust frame
	Body	Fiber glass
	Windshield	laminated
	Side rear view mirror	each on both sides
Interiors System	Seats	senior fabric leather + higher rebound PU
	Steering wheel	PU foaming steering wheel
	Floor	Anti-sliding Aluminum floor mat
Options	Color, rain curtains, seat belts, CD player, customers’ logo etc.

Product Show
