Help CenterChinese Cheap Oem 10kw Electric Trailer for Sale
Related Products
-
Chinese Oem 20-seats Electric Car Trailer for SaleNegotiableMOQ: 1 Set -
Chinese Oem Luxury Electric Bus for Tourist With 8 SeatsNegotiableMOQ: 1 Set
-
Cheap Oem Electric Tourist Bus With Open Roof for SaleNegotiableMOQ: 1 Set
-
OEM Long Range Electric Tourist Car With 8 SeatsNegotiableMOQ: 1 Set
-
OEM Open Top Tourist Bus for 8 Passengers Made in ChinaNegotiableMOQ: 1 Set
Specifications
electric classic car trailer
10kw motor
72v system
double 12*6v/220ah battery
Model |
Electric classic car |
Picture |
||
Technical parameter |
Out size(mm) |
5200×1680×1960 |
|
|
Wagon size(mm) |
5800×1680×1960 |
|||
Rated loading people |
20 |
|||
Max. speed(km/h) |
25 |
|||
Min. turning radius (m) |
≤5.5 |
|
||
Max. grade ability |
≤10% |
|||
Max. braking distance (m) |
≤4 |
|||
Max. mileage(km) |
80 |
|||
Min. ground clearance(mm) |
≥150 |
Wheelbase(mm) |
3345 |
|
Unloading weight(kg) |
1300 |
Wheel tread (mm) |
1425 |
|
Electric system |
Battery (domestic) |
6V-3-DG-220 battery,,6V/pc 220AH,24 pcs,double72V |
||
Charger (domestic) |
2 pcs 72V 25A, full-automatic charger |
|||
Controller (CURTIS) |
72 V 550A electronic communication |
|||
Motor |
72V/ 10KW DC series excited |
|||
Power operation |
Transmission system |
Rear engine drive |
||
Steering system |
pinion and rack steering assembly, automatic backlash compensation function |
|||
Front axel and suspension |
Macphersan independent suspension(helical spring +cylinder hydraulic shock absorber) |
|||
Rear axel and suspension |
Integral rear axel,spring nondependent suspension |
|||
Braking system |
vacuum assisted hydraulic brake system, electronic power steering, hand brake |
|||
Tyres |
steel wheel hub, tubeless tyre 185/70R13 |
|||
Outlook |
Paint |
High-end paint,mix paint by computer,professional spraying facility |
||
Body |
Superior carbon sq uare tube chassis+fiber glass bodies |
|||
Light |
Combinational front light,turning light,combinational rear light,horn and rear buzzer |
|||
Windshield |
Laminated glass |
|||
Inner decorations |
Seats |
Superior leather+ HR PU |
||
Meter |
Battery indicator DDLB-24/48R/002,ammeter 300A,voltmeter 60V |
|||
Switch |
starting,light and wiper combinational switch, front/rear changing direction switch |
|||
MP3 radio |
SV15 12V MP3 CD/radio |
|||
Our company was established in 2005, we are the manufacturer and trader specialized in machinery and electronics products. We mainly offer motors, electric bicycles, electric vehicles and its spare parts, bicycle and its spare parts, metallic materials, plastic products and textiles, etc.
We are located in Changzhou city, Jiangsu province, which is about 200km from Shanghai city, and 120km from Nanjing city.
Most of our products can comply with international quality standards and are greatly meeting in a variety of markets around the world . For example, we have EN15194 European certificate, CE certificate and EEC certificate. These certificates ensure us can enter into any country.
