BFK084S Refrigerator liquid line bi-directional filter drier

FOB Price

USD $18.6 - $19.7 / Piece

10 Pieces(Min.Order)

Supply Ability 10000 Piece / Pieces per Month
Port Shanghai
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shanghai, China		Brand Name	Emersion(Bi-directional filter drier)
Model Number	Filter drier(BFK084S)		After-sales Service Provided	No overseas service provided

Product Description

Specifications

BFK084S Refrigerator liquid line bi-directional filter drier
1. Best price
2. CE approved
3. High quality

Product Description

BFK084S Refrigerator liquid line bi-directional filter drier

Product Introduction

Liquid line filter-driers are often referred to as system protectors because they remove harmful elements from the

circulating refrigerants and lubricants before serious damage results. No matter how many precautions are taken

during assembly and installation or servicing of a system, contaminants can find (generate) their way into the system.

These contaminants can be solid, such as metal swarf, flux, dust and dirt.

Other equally menacing contaminants are soluble, such as water, acid and wax.

Construction

The active drying material is in the form of solid block. The solid block is a mixture of molecular Sieve and Activated Alumina.

These adsorbent are formed into a solid block and are held together by a Synthetic binding material.

The solid block is held tightly at both ends. The cushion felt pads for protection of the block are located at the ends of the block.

The internal check valves deflect flow in order the BFK be suitable for installation in Bi-flow directional of liquid in heat pump systems.

The internal block and felt pads insure the proper filtration.

ALCO (Emerson) BFK filter-driers incorporate a desiccant specially formulated and blended from 75% Molecular Sieves and

25% Activated Alumina for maximum moisture and sufficient acid removal capability.

Specifications

• Filtration first for more effective use of surface area of desiccant

• High moisture and acid removal capacity

• Solid copper connections

• Corrosion resistant epoxy powder paint finish

• Approved for POE oils with Copeland™ compressors

• Shock resistant steel shell construction

Technical data
