QI transmitter wireless charger mat wireless charging for samsung

Specifications

QI transmitter wireless charger
Spec:
pact&simple qi
2.slim,saving space & easy handling
3.low radiation, high power

QI transmitter wireless charger mat wireless charging for samsung





Model No.	Qi 002
Product Standard	Qi Standard
Input Voltage	DC 5V
Input Current	1000mA
Transmission Power	DC5W
Working Frequency	100-200Khz
Charging Voltage	DC5V
Charging Current	700-mA
Power Distance	5mm
Operating Temperature	-10°C- 40°C
Dimension	160x88x9mm
Weight	85g
Color	White/Black/Yellow/Green
Certificates	CE/ROHS/FCC
Warranty	6 months





















































What's Qi?

Wireless Charging Technology

Wireless charging technology facilitates the transmission of electrical energy from a power source to an electrical load without connecting wires. The technology is especially useful in cases where wires are hazardous, impossible to connect, or simply inconvenient.













Qi wireless charging standard

Qi is an interface standard developed by the Wireless Power Consortium for inductive electrical power transfer over distances of up to 4 cm (1.6 inches).

The Qi system comprises a power transmission pad and a compatible receiver in a portable device.To use the system,the mobile device is placed on top of the power transmission pad, which charges it via electromagnetic induction.









Charging Instructions





1. Plug the power adapter into the DC input, then connect it to a power outlet. The green power indicator will turn on in approximately 0 - 3 seconds.



2. Place your device on the eletromagnetic conversion emission area.



3. After about 0 - 3 seconds, the charger bee on and the green power indicator will start to flash.
