42U Network Server Cabinet

Name: 42U Network Server Cabinet
Brand: Rongli
SKU: 126350199
Availability: InStock

US$ 20 - 500 MOQ: 1 Piece

Key Specifications

Products Status:

Used

Cabinet Standard:

ANSI/SIA;RS-310-D;IEC297-2;DIN41491:PART1;DIN41494:PART7;GB/T3047.

Material:

SPCC, SPCC cold rolled steel 2.0mm

Ningbo Yinzhou Rongli Metal Product Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Products Status Used

Cabinet Standard ANSI/SIA;RS-310-D;IEC297-2;DIN41491:PART1;DIN41494:PART7;GB/T3047.

Material SPCC, SPCC cold rolled steel 2.0mm

Size 680*680*1072

Place of Origin Zhejiang, China

Brand Name Rongli

Model Number RLC008

waterproof network cabinet

1:Easy to fix concentrated distribution unit into frame;

2:popular front door with 5mm toughened glass ;

3:Removeable front/rear door and side panels, easy to install and unistall;

4. The firm structure, high bearing load, the maximum load of 500 kg (using the support or the base)

5:Bottom with cable entry, optional cover to close;

6:Wire path on the top and bottom can be closed, and wire holed dimensions can be changed as requested;

7:Wire groove with cover plus on the two sides in the front;

8:Groove cover can be install and unistall quickly and easily to maintain;

9:Interior space can reach 740mm max;

10:Install caster and support feet at the same time;

11.Accessories are complete, reliable quality

12. According to the customer request (specifications and structure change).

The product conforms to ANSI/SIA; RS - 310 - D; IEC297-2; DIN41491: PART1. DIN41494: PART7; GB/T3047.2-92 standard, compatible ETSI standards

RLC-008 Network Cabinet Specification
Model	Width	Deepth	Height	Capacity	Measurement	Valume
RL-0046618	600	600	992	18	6806801072	0.4957
RL-0046818		800			6808801072	0.6415
RL-0046918		900			6809801072	0.7144
RL-0046A18		960			68010801072	0.7873
RL-0046622	600	600	1081	22	6806801160	0.5364
RL-0046822		800			6808801160	0.6941
RL-0046922		900			6809801160	0.7730
RL-0046A22		960			68010801160	0.8519
RL-0046627	600	600	1303	27	6806801383	0.6395
RL-0046827		800			6808801383	0.8276
RL-0046927		900			6809801383	0.9216
RL-0046A27		960			68010801383	1.0157
RL-0046632	600	600	1525	32	6806801605	0.7421
RL-0046832		800			6808801605	0.9604
RL-0046932		900			6809801605	1.0696
RL-0046A32		960			68010801605	1.1787
RL-0046637	600	600	1748	37	6806801830	0.8462
RL-0046837		800			6808801830	1.0951
RL-0046937		900			6809801830	1.2195
RL-0046A37		960			68010801830	1.3440
RL-0046642	600	600	1970	42	6806802050	0.9480
RL-0046842		800			6808802050	1.2267
RL-0046942		900			6809802050	1.3661
RL-0046A42		960			68010802050	1.5055
RL-0046647	600	600	2192	47	6806802272	1.0508
RL-0046847		800			6808802272	1.3596
RL-0046947		900			6809802272	1.5141
RL-0046A47		960			68010802272	1.6686
