YM21A Roll Slitting Machine

YM21A Roll Slitting Machine thumbnail-1
YM21A Roll Slitting Machine photo-1
US$ 11,500 - 12,300 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Apparel, Textiles
Packaging Type:
Bags, Cartons
Contact Supplier Request Quote Chat Now
Shanghai Yimai Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Apparel, Textiles
Packaging Type Bags, Cartons
Packaging Material Paper
Automatic Grade Automatic
Driven Type Hydraulic
Voltage 110~380V
Power 1000
Place of Origin Shanghai, China
Brand Name YIMAI
Model Number YM21A
Weight 0.8T
Dimension(L*W*H) 1300
Certification No
After-sales Service Provided Engineers available to service machinery overseas

 Used to cut the straight girdle list of various widths in the industries of garments, interlining, and glued punch tapes with PLC automatic controller. 1) Human-Computer interface, PLC control.
2) AC drives the motor, cutting tolerance +/- 0.1mm.
3) The cutting width is automatically controlled by the stepper motor and preseted position. The blade is controlled by gear motor with infinite shift.
4) Whetstone and grinding motor fixed in cutting table.
5) The hydraulic pressure can be adjusted in the incision blade electronic hydraulic pressure station
6) High precision guide rail, knife frame, and dustproof shell.

Item

Parameter

Max. slitting width (mm)

1200

1600

1800

Min. width of the slitting strips (mm)

>20

Max. diameter of the log roll (mm)

230

Min. diameter of the inner core(mm)

35

45

Power supply( kw )

4.5 (380V)

Dimensions (L×W×H cm)

270×90×120

310×90×120

330×100×150

Weight (kg)

1000

1200

1500



YM21A Roll slitting machine



YM21A Roll slitting machine
