2014 Hot Products Azbox Premium HD+

Specifications

Anhui Risesat Electronics Co.,LTD

       2014 hot product  Azbox premium HD+

AzBox Premium HD+ plus
1.100% same original +fast ship
2.best price+support
3.factory not AzBox Premium HD+ reseller

AzBox Premium HD+ plus

 a true High-end receiver, with two plug and play tuner
slots ( You can make combinations as You like it with DVB-S, DVB-T and DVB-C ).
As this receiver is capable to receive all kind of signals, from satellite,
terrestrial and cable networks, it is also complete Full HD 1080p media player
capable to preview all kind of media ( video, audio, pictures ) contents. Also
it has integrated plug-ins which allow you to Browse internet, RSS Reader and
YouTube player. You can enjoy in this internet entertainment without connection
your AzBox HD Premium to Your router with wired cable, because AzBox HD Premium
comes with integrated Wi-Fi module.

TV
/ Radio Reception

At TV/Radio
part, Azbox HD Premium high quality hardware with
clear picture function make you enjoy the High definition images like never saw.

At software
on TV Part this receiver is very easy to operate, simple to navigate on all
menus and at same time you can personalize almost parameters related with
reception of audio and video.

Support for full High Definition format 1080P

Azbox
becomes one of small number of receiver that can be able to reproduce full 1080p
contents; this picture is much clearer, showing more details, and more relaxing
for your eyes. Enter the full HD world with Azbox!

Personal (Digital) Video Recorder and Time shift function

You can
record one channel and watch another (in case that you have bought one
additional tuner).

Time Shift
Function you can stop live broadcasting and shift back the time where you wish
to watch from the previously broadcasted.

Advanced Electronic Program Guide

With Azbox
you can enjoy a 7 Days EPG (Electronic program guide). You can also plan record
of your favorite programs based on EPG data.

At EPG we
also have search function to don’t lose your favorite programs and shows.

Support for a wide range of encryption systems

Azbox is
equipped with two CI slots (Common Interface) as well as one card readers that
provide a wide range of decoding options, this means Azbox Premium
HD is optimally prepared for any future developments in encryption standards.

Internet Browser

With Your Azbox HD you can comfortably
surf on internet using Azbox browser, read your news using RSS news reader, or
simply watch you favorite YouTube movies suing our YouTube portal.

 GOGO List function

With this
function you can download your favorite list from internet. No longer need be
concerned about changing channel frequencies, just select GOGO list and your
channel list will be downloaded, updates and channel lists will be sorted
according your wishes.

Connectivity

Azbox
Premium HD products are equipped with a high range of
connectors: 2 USB connectors that allow users to connect portable media or
external USB HDD, for use USB like internal HDD for PVR / time shift and media
center functions.

Also is
equipped with HDMI (High-definition multimedia interface) output to enjoy the
best picture and audio quality.

However to
keep the possible to be used at all screens Azbox is also equipped with digital
optical audio output, Composite video (YPBPR), Video and stereo audio RCA and
one scart connector.

Internally you
have also a SATA socket for internal HDD up to 1000 GB).

Premium model is also equipped with a Wi-Fi module, with this hardware you can
have internet at your Azbox HD premium without need cross your
home with Ethernet cables.

Modular tuners sockets

One of or
top hardware features is that the tuners can be easily switched so you can easy
transfer you DVB-S2 receiver at one combo receiver. You have all freedom to pick
u any desired combination that more adjusts to your needs (Available tuners:
DVB-T, DVB-C, DVB-S2, ATSC and ISDB-T (Brazilian format)).

Media Player

With the
Media Player functionality you can watch and listen to various media files from
MP3 to MKV files (with support for subtitles) and also watches your photos.

All this by
simply plugging a USB stick with your media files, it’s also possible to copy
your USB stick content to the internal disk drive or access your media files
direct over your local network.

VFD
Display

Program
related information and system operations are displayed via the 11-digit vacuum
fluorescence display (VF display) on the elegant front panel of the receivers.

Main Features

• Sigma Designs SMP8634LF CPU
• Linux Operative System
• 128 MB DDR System Memory
• 128 MB DDR Video Memory
• Big Storage memory (Nor Flash 8MB, DOM 256MB),
  total flash memory 264 MB
• PAL and NTSC Video Output formats
• Support resolution up to 1080p (supported
  resolutions: 576i (480i), 576p (480p), 720p, 1080i, 1080p)


• Supported Video Containers: MPEG1/2/4 (M1V, M2V,
  M4V); MPEG1/2 PS (M2P, MPG); MPEG2 Transport Stream (TS, TP, TRP,
  M2T, M2TS, MTS), VOB, AVI, ASF, WMV, IFO, ISO; Matroska (MKV), MOV
  (H.264), MP4, RMP4
• Supported Video Codec’s:  XVID SD/HD; DIVX;
  MPEG-1; MPEG-2: MP#HL; MPEG-4.2: ASP#L5, 720p, 1-point GMC; WMV9:
  MP#HL; H.264: BP#L3; H.264: MP#L4.0; H.264: HP#L4.0; H.264: HP#L4.1;
  VC-1: MP#HL; VC-1: AP#L3
• Supported Audio Containers: AAC, M4A, MPEG audio
  (MP1, MP2, MP3, MPA), WAV, WMA, FLAC, Ogg
• Supported Audio Codec’s:  AAC; AAC +; Dolby
  Digital, WMA, WMA Pro, MP1, MP2, MP3, LPCM, FLAC, Vorbis, Audio
  Passthrough: DTS; Dolby Digital
• Supported subtitles formats: SMI, SRT, TXT, SUB,
  SSA
• Supported pictures formats: JPEG, BMP, GIF

• Input Frequency: 950 ~ 2150Mhz
• Modulation: QPSK, 8PSK
• FEC: 1/2, 2/3, 3/4, 3/5, 4/5, 5/6, 6/7, 7/8, 8/9,
  9/10
• Demodulation IC: CX24116
• Input Impedence: 75O
• IF Frequency: 36.128Mhz

• 1x HDMI
• 2x RCA Audio (L/R)
• 1x RJ45
• 1x USB 2.0
• 1x Optical S/PDIF
• 1x 0/12V
• 1x Power Switch

     Front I/O

• 1x Smartcard Reader; 1x USB 2.0; IR Modul; Buttons: Power, CH+, CH-, Vol+, Vol-, OK
• RCU with batteries, power adapter
  and power cable

BASIC FEATURES:
Linux as the operating system
PVR (recording) internal or external
WLAN (wireless to Internet)
NG RACE GoGo List (online station list update)
Webradio
Support video portals such as YouTube and other video
Audio & Music portals
RSS feeds
1080p resolution
Smart Tuner Support
DVB-S2 / S, DVB-T2 / T (DVBs2 and DVB-T from the factory)
DVB-C2 / C, ISDB-T
GO GO List function (Intelligent Channel sorting)
MPEG4 HD and fully DVB compatible
11 digit VFD display
3 Front panel buttons (Power, channel up, channel down)
7 day EPG 7 day EPG
Personal Video Recorder:
Function time shift (pause and play live TV, time-recording of programs)
Receiver streaming (audio / video and radio)
Video On Demand
Wireless and RJ45 connection Wirelessly over WLAN and via RJ45 connection
Web interface for remote control of the receiver's
Update on the Internet, USB and serial port for update
Web browser
RSS newsreader
E-mail client (POP Only)
Media Player :
Audio formats: MP3, WAV, AIFF, WMA, Ogg Vobis
Image: JPEG, BMP, TIFF, GIF, PNG
Video: MPEG1, MPEG2, MPEG4, DivX, XviD, MKV, AVI SSF (incl support subtitles)
Video-Audio A¨¹flösung: MPEG-2/MPEG-4 Part 10 AVC/H.264 HD, HPL4.0 1920x1080 50Hz
(MPEG-2 transport stream specification ISO/IEC13818)
Input: max 90 MB /sec
Aspect ratio: 4:3, Letterbox, 16:9, Pan & Scan
In / Out connectors
1 Smart Card Reader
2 x USB 2.0 (left side and front panel)
HDD LAN via Samba
IDE hard disk can be installed internally
Digital Optical output
HDMI port
YUV / YUV Component Out / Component output
UHF connection
Physical properties:
Size: 170x130x30mm
Storage Temperature: -20 C ~ 75 C
Power: 90 VAC ~ 240 VAC power switch
Max 40 Watt
