Factory Price C/KU BAND LNBF C BAND LNBF KU BAND LNBF
US$ 1 - 16.5
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Anhui, China
Brand Name:
risesat
Model Number:
RS-L600
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
KU Band Universal OCT0 LNBFUS$ 9.96 - 13.59MOQ: 100 Pieces -
Low Noise KU BAND Quad LNBF, Universal HD LNBF Factory PriceUS$ 1.1 - 5.4MOQ: 1000 Pieces
-
Low Noise KU BAND TWIN LNBF, Universal HD Dual LNBF Lowest Factory PriceUS$ 1 - 3.5MOQ: 100 Pieces
-
Factory Low Noise Single KU BAND LNBF ku Single LnbfUS$ 0.99 - 1.35MOQ: 1000 Pieces
-
Ku Universal Single LNBFUS$ 0.98 - 1.19MOQ: 1000 Pieces
Place of Origin
Anhui, China
Brand Name
risesat
Model Number
RS-L600
Specifications
C/Ku Band LNBF1.high gain Dual Band LNBF
2.superior signal quality
3.Factory lowest price
ANHUI RISESAT ELECTRONICS CO.,LTD
C/KU BAND LNBF
Product Description
| SPECIFICATIONS | ||
| MODEL | DP-C+KU-DS | |
| C | KU | |
| SWITCHING | DiSEqc-A(1) | DiSEqc-B(2) |
| INPUT FREQUENCY | 3.4-4.2 GHz | 10.7-12.75 GHz |
| L.O. FREQUENCY | 5.15 GHz | 9.75/10.6GHz |
| STABILITY | ±2 MHz(-40 °C - +70 °C) | ±2 MHz(-40 °C - +70 °C) |
| L.O. PHASE NOISE | -55 dBc/Hz@1KHz -85 dBc/Hz@10KHz -105 dBc/Hz@100KHz |
-70 dBc/Hz@1KHz -90 dBc/Hz@10KHz -105 dBc/Hz@100KHz |
| OUTPUT FREQUENCY | 950-1750 MHz | 950-2150 MHz |
| CONVERSION GAIN | 65 dB (TYP) | 65 dB (TYP) |
| GAIN FLATNESS | ±0.5 dB/36 MHz | ±0.5 dB/36 MHz |
| NOISE FIGURE | 17°K | 0.3dB |
| INPUT V.S.W.R | 2.5:1 | 2.5:1 |
| OUTPUT V.S.W.R | 2.5:1 | 2.0:1 |
| CROSS POLAR ISOLATION | 23dB MIN | 23dB MIN |
| SUPPLY CURRENT | 130 mA (MAX) | 130 mA (MAX) |
| OPERATING TEMPERATURE | -40 °C ~ +70 °C | -40 °C ~ +70 °C |
| RELATIVE HUMIDITY | 0%~95% | 0%~95% |
| IF OUTPUT CONNECTER | "F" TYPE FEMALE | "F" TYPE FEMALE |
| OUTPUT IMPEDANCE | 75 OHMS | 75 OHMS |
WELCOME TO VISIT OUR FACTORY.
