Help Center5T Wheel Loader Lonking CDM856E
Related Products
Specifications
Model Number CDM 856EBucket Capacity 3m3
Rated Load 5000kg
Rated Power 160kw
Operating Weight 18860kg
Overall Data of wheel loader CDM856E:
Traction Force :(kn): 155±3
Breakout Force (kn): 170±3
Engine: DF CUMMINS 6CTA8.3-C215
Drive Train:
Torque Converter: Single-stage, Duo-turbine, 4-elements
Transmission: Planetary power shift Transmission
Gear: 2F/1R
Main Reducer: Spiral bevel,1-stage Reduction
Final Reducer: Planetary Reduction
Tire: 23.5-25 L-3 16PR
Brake System:
Service Brake: Duo Circuit Caliper, Dry Brake
Parking Brake: Air Actuated Caliper Brake
Emergency Brake: Air Actuated Caliper Brake
Steering System:
Type: Hydraulic Load Sensing
Please open below link to down the brochure of Lonking CDM856E wheel loader:
/s/be20fc222b24db251454
